1. 3.5 inch LCD Colour Screen (SATLINK WS6906) 2. Live FTA Digital Picture and Sound 3. AV in and AV out function 4. Watch the free channels 5. Sound warning prompt locking satellite 6. Bit Error Rate Readout 7. Carrier to Noise Readout 8. dBuV Readout 9. Lithium-ion 1950mA battery 10. DiSEqC & 22kHz Switch Control 11. Fully DVB Compliant (SATLINK WS6906) 12. Freq range: 950mHz-2150mHz 13. Signal level: 65dbm-25dbm 14. Symbol rate: 2mbps-45mbps 15. Video format: PAL, NTSC, SECAM 16. Software Upgradeable via USB 17. Charger: 90 - 240V 18. Supply voltage: 12.6V 19. USB Cable & Strap 20. Video decoder: MPEG 2 (Main Proflie at Main Level), Data Rate (up to 15M bits/s), Resolution (720*576,720*480), Video format (PAL/NTSC/SECAM). 21. LNB/Tuner input: Connector (F type, male), frequency range (950MHz-2150MHz), Signal lever (-65dBm-25dBm), LNB supply (13/18V, up to 400mA), LNB switch control (22KHz), DiSEqC (Ver 1.0). 22. MPEG Audio:Sampling rates(3244.1 and 48KHz). 23. Digital tuner input: F type, male.Specification: General Model WS6906 Frequency range 950mHz-2150mHz Power Supply 90 - 240V Working Voltage 12.6V Battery Lithium-ion 1950mA battery Size 158x95x45mm Weight 500g Package Include Package Contents 1 x User manual 1 x AV Cable 1 x USB Cable 1 x Power Supply (EU, US, AU, UK Optional) 1 x Car Charger 1 x Host 1 x Buckle Rope Package Weight One Package Weight 1.20kgs / 2.65lb One Package Size 21cm * 18cm * 6cm / 8.27inch * 7.09inch * 2.36inch Qty per Carton 20 Carton Weight 26.50kgs / 58.42lb Carton Size 44cm * 38cm * 32cm / 17.32inch * 14.96inch * 12.6inch Loading Container 20GP: 498 cartons * 20 pcs = 9960 pcs40HQ: 1157 cartons * 20 pcs = 23140 pcs

Read more less

Features1. 3.5 inch high definition TFT transmissive LCD screen, 480(RGB) x 272 pixel, 70.02x52.58mm active area. 2. Fully DVB S/DVB S2, MPEG2/MPEG4 compliant, MPEG2 / H.264 hardware decoding. 3. Digital meter for signal strength and quality. 4. Support scan of auto, blind, manual or NIT. 5. Sound and light alarm for locking signal. 6. Auto calculate angle of AZ, EL. 7. Support DISEQC 1.0/1.1/1.2, 0/22KHz tone. 8. Speaker integrated. 9. Support both AV out and AV in. 10. LNB supply: 13V/18V, Max 400mA, LNB short protect. 11. 7.4V/3000mAh li-ion battery included. 12. Software upgrade via USB port. 13. Easy to carry. 14. Demodulation Type: QPSK, 8PSK. 15. Symbol rate: 2 less than Rs less than 45M band (SCPC/MCPC). 16. Input frequency 950~2150MHz, signal input level -65~ -25dBm, band switch control: 22KHz. 17. AV output / input interface: 3.5mm jack, CVBS video output / input, stereo audio L/R output / input.Video Decompression1. Resolving rate: PAL 25 frame at 720 x 576, NTSC 30 frame at 720 x 480. 2. Signal compatibility: Support conversion for different video formats. 3. Video format: 4:3, 16:9, by pan & scan and letter box conversion. 4. Audio decompression: MPEG1 Layer I/II, MPEG2 Layer I/II. 5. Audio output mode: Stereo, Mono, R/L.Specification: Package Weight One Package Weight 1.11kgs / 2.45lb One Package Size 23cm * 22cm * 7cm / 9.06inch * 8.66inch * 2.76inch Qty per Carton 20 Carton Weight 23.50kgs / 51.81lb Carton Size 48cm * 46cm * 37cm / 18.9inch * 18.11inch * 14.57inch Loading Container 20GP: 326 cartons * 20 pcs = 6520 pcs40HQ: 757 cartons * 20 pcs = 15140 pcs
