Products

1. Frequency Range: VHF: 144-146MHz (136-174MHz), UHF: 430-440MHz (400-490MHz), FM: 86.7-108MHz 2. Number of Channels: 200 3. Channel spacing: 25KHz(Wide Band), 12.5KHz (Narrow Band) 5. Phrase-lock step: 2.5KHz, 5Khz, 6.25KHz, 10KHz, 12.5KHz, 15KHz, 20KHz, 25KHz, 30KHz, 50KHz 6. Operating voltage (ordinary): DC 13.8V+/-15% 7. Operating voltage (wide voltage): DC 12-28V 8. Squelch method: Carrier/CTCSS/DCS/5tone/2tone/DTMF 9. Frequency stability: +/-2.5ppm 10. Operating Temperature: -20~+60 degree C 11. Dimensions: 124 (W) x 101(D) x 36 (H)mm 12. Weight: About 0.45Kg Transmitter Part 1. Power Output: (UHF/VHF)Wide Band / Narrow Band: 25W/10W/5W 2. Modulation: Wide Band: 16K x F3E, Narrow Band: 11K x F3E 3. Adjacent Channel Power: Wide Band: >=70dB, Narrow Band: >=60dB 4. Hum & Noise: Wide Band: >=40dB,Narrow Band: >=36dB 5. Spurious Emission: Wide Band: >=60dB, Narrow Band: >=60dB 6. Wide Band: Audio Response: +1~-3dB (0.3~3KHz), Narrow Band: +1~-3dB (0.3~3KHz) 7. Audio Distortion: =<5% Receiver Part 1. Sensitivity (12dBm SINDA): Wide Band: =<0.25uV, Narrow Band: =<0.35uV 2. Adjacent Channel Selectivity: Wide Band: >=70dB, Narrow Band: >=60dB 3. Audio Response: Wide Band: +1~-3dB (0.3~3KHz), Narrow Band: +1~-3dB (0.3~2.55KHz) 4. Noise Ratio: Wide Band: >=45dB, Wide Band: >=40dB 5. Audio distortion: 3% 6. Audio power output: >2W@10%Specification: General Certificate GPSR Package Weight One Package Weight 0.84kgs / 1.86lb One Package Size 20cm * 15cm * 8cm / 7.87inch * 5.91inch * 3.15inch Qty per Carton 20 Carton Weight 17.80kgs / 39.24lb Carton Size 42cm * 32cm * 35cm / 16.54inch * 12.6inch * 13.78inch Loading Container 20GP: 566 cartons * 20 pcs = 11320 pcs40HQ: 1316 cartons * 20 pcs = 26320 pcs

Read more less

1. Frequency Range: VHF:136-174MHz UHF:400-480MHz2. Number of Channel: 2003. Channel Spacing: 25KHz, 20K, 12.5K4. Phase lock step: 5KHz, 6.25KHz, 10KHz,12.5KHz, 15KHz, 25KHz5. Working Voltage: 13.8V DC +/- 15%6. Squelch way: CTCSS/DCS/5Tone/2Tone/DTMF7. Frequency stability: +/- 2.5ppm8. Operating temperature: -20~+60 degrees Celsius9. Dimension: 98(W) x 35(H) x 118(D)mm10. Weight: 408gSpecification: Package Weight One Package Weight 0.60kgs / 1.33lb One Package Size 18cm * 12cm * 5cm / 7.09inch * 4.72inch * 1.97inch Qty per Carton 30 Carton Weight 19.60kgs / 43.21lb Carton Size 38cm * 38cm * 27cm / 14.96inch * 14.96inch * 10.63inch Loading Container 20GP: 683 cartons * 30 pcs = 20490 pcs40HQ: 1587 cartons * 30 pcs = 47610 pcs

Read more less

1. Frequency range: VHF: 136-174MHz, UHF: 400-480MHz2. Number of channels: 2003. Channel spacing: 25KHz, 20K, 12.54. Phase lock step: 2.5 KHz, 5 KHz, 6.25 KHz, 10 KHz, 12.5 KHz, 15 KHz, 25 KHz5. Working voltage: 13.8V DC +/- 15%6. Medium size silencer: CTCSS, DCS, 5 tone, 2 tone, DTMF7. Frequency stability: add 2.6ppm8. Working temperature: -20 - +60 degrees Celsius9. Size: 98 x 43 x 126mm10. Weight: 448gSpecification: Package Weight One Package Weight 0.93kgs / 2.05lb One Package Size 22cm * 13cm * 7cm / 8.66inch * 5.12inch * 2.76inch Qty per Carton 30 Carton Weight 20.00kgs / 44.09lb Carton Size 44cm * 36cm * 30cm / 17.32inch * 14.17inch * 11.81inch Loading Container 20GP: 561 cartons * 30 pcs = 16830 pcs40HQ: 1302 cartons * 30 pcs = 39060 pcs

Read more less

1. Frequency range: VHF: 136-174MHz, UHF: 400-480MHz2. Number of channels: 2003. Channel spacing: 25KHz, 20K, 12.5K4. Phase lock step: 2.5KHz, 5KHz, 6.25KHz, 10KHz, 12.5KHz, 15KHz, 25KHz5. Working voltage: 13.8V DC +/- 15%6. Squelch mode: Carrier / CTCSS / DCS / 5Tone / 2Tone / DTMF7. Frequency stability: +/- 2.5ppm8. Operating temperature: -20 - +60 degrees Celsius9. Dimensions: 140x43x172mm10. Weight: 1.03kgPacking list:- 1 x QYT 980 Plus car radio- 1 x External microphone- 1 x Car power cable- 1 x Mounting bracket- 1 x Screw kitSpecification: Package Weight One Package Weight 1.71kgs / 3.76lb One Package Size 30cm * 18cm * 6.5cm / 11.81inch * 7.09inch * 2.56inch Qty per Carton 10 Carton Weight 18.20kgs / 40.12lb Carton Size 55cm * 30cm * 35cm / 21.65inch * 11.81inch * 13.78inch Loading Container 20GP: 461 cartons * 10 pcs = 4610 pcs40HQ: 1071 cartons * 10 pcs = 10710 pcs

Read more less

1. Frequency range: VHF: 136-174 MHz, 245-245.9875 MHz (220-260 MHz); UHF: 400-490 MHz2. Number of channels: 200 channels3. Transmit power: 60 W4. Channel spacing: 25 kHz (wideband), 20 kHz (midband), 12.5 kHz (narrowband) 5. Frequency stability: ±2.5 ppm6. Operating temperature: -20 to 60 degrees Celsius7. Operating voltage: DC 13.8 V +/- 15%8. Size: about 19 x 14.5 x 4.7 cm9. Weight: About 1.2 kgReceiver:1. Sensitivity (12 dB SINAD) wideband/narrowband: ≤0.25 μV / ≤0.35 μV 2. Adjacent channel selectivity (wideband/narrowband): ≥70 dB / ≥60 dB 3. Spurious response (wideband/narrowband): ≥65 dB / ≥60 dB 4. Spurious suppression (wideband/narrowband): ≥70 dB 5. Audio response (wide/narrowband): +1 to -3 dB (0.3–3 kHz) / +1 to 3 dB (0.3–2.55 kHz)6. Electromagnetic interference and noise (wide/narrowband): ≥45 dB / ≥40 dB7. Audio distortion: ≤5% 8. Audio power output: greater than 2W ±10%Transmitter:1. Output power (wideband/narrowband): 60W/25W/10W (VHF), 45W/25W/10W (UHF) 2. Modulation (wideband/narrowband): 16K F3E / 11K F3E 3. Adjacent channel power (wideband/narrowband): ≥70 dB / ≥60 dB 4. Signal-to-noise ratio (wideband/narrowband): ≥40 dB / ≥36 dB 5. Spurious and harmonic distortion (wideband/narrowband): ≥60 dB 6. Audio response (wideband/narrowband): +1 to -3dB (0.3–3kHz) / +1 to -3dB (0.3–2.55kHz) 7. Audio distortion: ≤5%Features:1. The housing is made of eco-friendly PC and polycarbonate, offering high strength, precision, and heat resistance, with reinforced, wear-resistant, and drop-proof construction.2. Strong penetration capability ensures longer communication distances; stable and reliable transmission power combined with high reception sensitivity guarantees long-range communication and signal coverage.3. Features a large LCD screen for clear, intuitive, and convenient display of all information; built-in indicator lights allow for effortless operation even at night.4. 60W high power output, high efficiency, and low energy consumption; high power ensures strong signal penetration5. Equipped with a simple yet sturdy handheld microphone; buttons are clear and durable, offering easy operation, a comfortable grip, and robust durability6. Features a DPS noise reduction system with an ultra-high noise reduction ratio7. Circuit boards are made of aluminum alloy for superior heat dissipation, ensuring stable and high-quality communicationPackage list:1. Main unit x 12. Mounting bracket x 13. Mounting screw kit x 14. Power cord x 15. Handheld microphone x 16. User manual x 1Specification: Package Weight One Package Weight 1.80kgs / 3.98lb One Package Size 35cm * 26cm * 10cm / 13.78inch * 10.24inch * 3.94inch Qty per Carton 5 Carton Weight 10.00kgs / 22.05lb Carton Size 47cm * 35cm * 27cm / 18.5inch * 13.78inch * 10.63inch Loading Container 20GP: 600 cartons * 5 pcs = 3000 pcs40HQ: 1393 cartons * 5 pcs = 6965 pcs

Read more less
