Sensormodul
-
Waveshare Waveshare OS05A20 5MP USB Camera Module C Type 91.7-degree FOV Distortion-free Lens, 35565
1. OS05A20 5MP USB Camera module, equipped with an OS05A20 5-megapixel sensor chip. The module features a USB 2.0 Type-C interface, plug-and-play, and supports MJPG format 30 FPS output.2. Equipped with a 91.7-degree distortion-free lens, reducing image deformation.3. Supports dual-exposure on-chip HDR, maintaining image detail even in low-light environments.4. Onboard single microphone, supporting USB audio recording.Specifications:1. Pixels: 5 MP2. Sensor chip: OS05A203. Interface type: USB 2.04. Camera:-- Sensor size: 1/2.7 inch-- Aperture (F): 2.4-- Focal length (EFL): 3.25 mm-- Field of view (FOV): 91.7 deg-- Distortion: < -1.22%-- Focusing method: Fixed focus5. Lens thread: M126. Shutter type: Rolling shutter7. Image:-- Supported format: MJPG-- Still image resolution: 2592 x 19448. Video recording support:-- 30 FPS 2592 x 1944-- 30 FPS 1920 x 1080-- 30 FPS 1280 x 7209. Dynamic range: 74 dB10. Operating voltage: 5V +/- 5%11. Operating temperature: -10 to 60 degrees C12. Module dimensions: 25 x 24 (mm)Specification: Package Weight One Package Weight 0.07kgs / 0.16lb One Package Size 15cm * 8cm * 5cm / 5.91inch * 3.15inch * 1.97inch Qty per Carton 64 Carton Weight 5.60kgs / 12.35lb Carton Size 32cm * 34cm * 42cm / 12.6inch * 13.39inch * 16.54inch Loading Container 20GP: 583 cartons * 64 pcs = 37312 pcs40HQ: 1354 cartons * 64 pcs = 86656 pcs
£47.99
-
Waveshare Waveshare OS05A20 5MP USB Camera Module Type B Supports USB2.0 Port, 35566
1. OS05A20 5MP USB Camera module, equipped with an OS05A20 5-megapixel sensor chip. The module features a USB 2.0 Type-C interface, plug-and-play, and supports MJPG format 30 FPS output.2. Equipped with a 175-degree ultra-wide-angle lens to capture wide scenes.3. Supports dual-exposure on-chip HDR, maintaining image detail even in low-light environments.4. Onboard single microphone, supporting USB audio recording.Specifications:1. Pixels: 5 MP2. Sensor chip: OS05A203. Interface type: USB 2.04. Camera:-- Sensor size: 1/2.7 inch-- Aperture (F): 2.0-- Focal length (EFL): 3.65 mm-- Field of view (FOV): 175 deg (D) x 151.9 deg (H) x 83.6 deg (V)-- Distortion: < -32%-- Focusing method: Fixed focus5. Lens thread: M126. Shutter type: Rolling shutter7. Image:-- Supported format: MJPG-- Still image resolution: 2592 x 19448. Video recording support:-- 20 FPS 2592 x 1944-- 30 FPS 1920 x 1080-- 30 FPS 1280 x 7209. Dynamic range: 74 dB10. Operating voltage: 5V +/- 5%11. Operating temperature: -10 to 60 degrees C12. Module dimensions: 25 x 24 (mm)Specification: Package Weight One Package Weight 0.07kgs / 0.16lb One Package Size 15cm * 8cm * 5cm / 5.91inch * 3.15inch * 1.97inch Qty per Carton 64 Carton Weight 5.60kgs / 12.35lb Carton Size 32cm * 34cm * 42cm / 12.6inch * 13.39inch * 16.54inch Loading Container 20GP: 583 cartons * 64 pcs = 37312 pcs40HQ: 1354 cartons * 64 pcs = 86656 pcs
£46.99
-
WAVESHARE Round-Shaped All-In-One Capacitive Fingerprint Sensor Onboard LED Indicator 192 x 192 Image Pixels, 35671
1. Easy to use, no need to understand fingerprint algorithms or internal structure. Just simple instructions can complete the corresponding operations2. Built-in commercial algorithms, supporting fingerprint input, fingerprint comparison, fingerprint image extraction and fingerprint feature value upload functions. Stable performance, fast recognition speed3. Capacitive fingerprint recognition, sensitive sensing, fingers can be quickly identified by gently touching the collection window4. High hardware integration, the main control and fingerprint sensor are integrated as one, convenient to embed in small-sized applications5. Built-in human body sensing device, with power-off sleep and touch wake-up functions, lower power consumption6. The collection window is equipped with LED, providing fingerprint collection indication7. Built-in UART serial communication interface8. Convenient to connect to PC for communication with the host computer, also supports embedded hardware platforms such as STM32 and Raspberry PiParameters1. Sensor type: capacitive touch sensor2. Resolution: 508 DPI3. Image pixel array: 192 x 1924. Fingerprint template size: 448 bytes5. Sensor size: 9.6 x 9.6 mm6. Fingerprint capacity: 10007. Comparison time: less than 0.5s (1 : N, and N is less than or equal to 500)8. Forgery rate: less than 0.001% (security level 3)9. False rejection rate: less than 2% (security level 3)10. Operating voltage: 3.3V11. Operating current: less than 60mA12. Electrostatic test: SD IEC 61000-4-2 LEVEL 4 ±15KV airborne discharge13. Communication interface: UART (TTL)14. Communication baud rate: 115200bps (supports 9600bps - 115200bps)15. Working environment: temperature: -10°C - 60°C; humidity: 0%RH - 90%RH (no frost formation)16. Packaging list: UART Fingerprint Sensor (G) x 1, SH1.0 6PIN connection cable about 150mm x 1, SH1.0 6PIN double-ended cable about 170mm x 1Specification: Package Weight One Package Weight 0.02kgs / 0.04lb One Package Size 5cm * 5cm * 4cm / 1.97inch * 1.97inch * 1.57inch Qty per Carton 504 Carton Weight 9.00kgs / 19.84lb Carton Size 50cm * 37cm * 32cm / 19.69inch * 14.57inch * 12.6inch Loading Container 20GP: 450 cartons * 504 pcs = 226800 pcs40HQ: 1045 cartons * 504 pcs = 526680 pcs
£15.99
-
WAVESHARE PS5268 2MP M12 Camera Module Type B USB 2.0 Header High Dynamic Range, 35496
1. Pixels: 2 million2. Photographic sensor: PS52683. Interface type: USB 2.04. Sensor size: 1/2.7 inch5. Aperture (F): 2.26. Focal length (EFL): 2.28mm7. Field of view (FOV): 187.4° (D) x 156.7° (H) x 93.4° (V)8. Focusing mode: fixed focusing9. Distortion: Lless than -31%10. Dynamic range: 85dB11. Infrared filter: 650nm filter12. Image supported formats: MJPG, YUY213. Static image resolution: 1920 x 108014. Video recording support: MJPG: 30FPS 640 x 360; 30FPS 640 x 480; 30FPS 960 x 544; 30FPS 1280 x 720; 30FPS 1920 x 1080; YUY2: 10FPS 640 x 360; 10FPS 640 x 480; 5FPS 960 x 544; 5FPS 1280 x 720; 5FPS 1920 x 108015. Shutter mode: slit shutter16. Audio: built-in dual microphones17. Operating voltage: 5V ± 5%18. Module size: about 3.8 x 3.8 x 1.92 cmSpecification: Package Weight One Package Weight 0.05kgs / 0.11lb One Package Size 8cm * 8cm * 4cm / 3.15inch * 3.15inch * 1.57inch Qty per Carton 192 Carton Weight 10.00kgs / 22.05lb Carton Size 50cm * 34cm * 34cm / 19.69inch * 13.39inch * 13.39inch Loading Container 20GP: 461 cartons * 192 pcs = 88512 pcs40HQ: 1071 cartons * 192 pcs = 205632 pcs
£33.99
-
WAVESHARE IMX563 12MP OIS Camera Module 122-Degree Wide-Angle Lens Autofocus, 35215
1. MIPI CSI-2 4-Lane interface, using 24-pin board-to-board connector, suitable for embedded scenarios2. Dual-axis OIS optical stabilization system, ±3° shake compensation, ensuring stable motion images3. Built-in open-loop VCM, supporting automatic focusing, and automatically adjusting according to the shooting distance4. The module provides a 122° diagonal field of view, capable of capturing a larger environmental range5. Equipped with Sony IMX563 12-megapixel CMOS image sensor, featuring high sensitivity, low noise, and fast response performanceParameters1. Sensor model: for Sony IMX5632. Resolution: 4032 x 3024 (12 million pixels)3. CMOS size: 1/2.55 inch4. Pixel size: 1.4 x 1.4 micrometers5. Field of View (FOV): 122° (D) x 107.2° (H) x 90.1° (V)6. Aperture (F.No): 2.27. Focal length (EFL): 2.17mm8. Depth of Field: 10cm to infinity9. Distortion: less than 5.6%10. Focusing mode: automatic focusing11. Filter: built-in 650nm filter12. Shake reduction: OIS optical shake reduction (shake reduction angle ±3 degrees, greater than 25dB)13. VCM driver IC focusing: DW9800V14. VCM driver IC OIS: AKM732315. Frame rate: 120fps Full resolution / 240fps 4K2K / 960fps 1080p16. Output format: RAW 10/8 bit17. Interface: 24PIN board-to-board connector18. Operating temperature: -20°C to 70°CSpecification: Package Weight One Package Weight 0.01kgs / 0.03lb One Package Size 6cm * 5cm * 4cm / 2.36inch * 1.97inch * 1.57inch Qty per Carton 432 Carton Weight 6.00kgs / 13.23lb Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch Loading Container 20GP: 438 cartons * 432 pcs = 189216 pcs40HQ: 1018 cartons * 432 pcs = 439776 pcs
£37.99
-
WAVESHARE IMX563 12MP OIS USB Camera Autofocus Dual-Axis Optical Image Stabilization (OIS) USB 2.0 Type-C Port, 35687
1. USB 2.0 interface, with Type-C packaging, can be directly connected to computers, embedded motherboards and other devices2. Dual-axis OIS optical stabilization system, ±3° shake compensation, ensuring stable motion images3. Built-in open-loop VCM, supports automatic focusing, and can automatically adjust according to the shooting distance4. The module provides a 122° diagonal field of view, capable of capturing a larger environmental range5. Equipped with Sony IMX563 12-megapixel CMOS image sensor, featuring high sensitivity, low noise, and fast response performanceParameters1. Sensor model: for Sony IMX5632. Resolution: 4032 x 3024 (12 million pixels)3. CMOS size: 1/2.55 inch4. Pixel size: 1.4 x 1.4 micrometers5. Field of View (FOV): 122° (D) x 107.2° (H) x 90.1° (V)6. Aperture (F.No): 2.27. Focal length (EFL): 2.17mm8. Depth of Field: 10cm to infinity9. Distortion: less than 5.6%10. Focusing method: automatic focusing11. Filter: built-in 650nm filter12. Shake reduction: OIS optical shake reduction (shake reduction angle ±3 degrees, greater than 25dB)13. VCM Drive IC Focusing: DW9800V14. VCM Drive IC OIS: AKM732315. Frame rate: 120fps Full resolution / 240fps 4K2K / 960fps 1080p16. Output format: MJPEG17. Interface: Type-C USB 2.018. Operating temperature: -20°C to 70°C19. Product size: about 3.8 x 3.8cmSpecification: Package Weight One Package Weight 0.04kgs / 0.09lb One Package Size 8cm * 8cm * 4cm / 3.15inch * 3.15inch * 1.57inch Qty per Carton 192 Carton Weight 8.00kgs / 17.64lb Carton Size 50cm * 34cm * 34cm / 19.69inch * 13.39inch * 13.39inch Loading Container 20GP: 461 cartons * 192 pcs = 88512 pcs40HQ: 1071 cartons * 192 pcs = 205632 pcs
£72.99
-
Waveshare Waveshare 2MP GMSL Camera Module With 118.4-Degree Wide FOV Automotive-Grade Image Sensor, 35539
1. The GMSL-2MP-Camera camera module utilizes an automotive-grade 2MP CMOS image sensor, integrates a MAXIM MAX96717F GMSL serializer, and features a built-in professionally tuned Image Signal Processor (ISP) for clear and stable imaging performance. The entire housing achieves an IP67 protection level and comes standard with an AA lens, which undergoes precise focusing and dispensing fixation before leaving the factory, ensuring high reliability for harsh environments such as automotive applications.Parameters:Sensor:1. Model: 2.51MP RGGB2. Resolution: 1920 x 10803. CMOS Size: 1/2.57 inch4. Pixel Size: 3.0 x 3.0 umLens:1. Field of View (FOV): 118.4 deg (H) x 62.6 deg (V)2. Aperture (F.No): 23. Focal Length (EFL): 3.04 mm4. Depth of Field (DOF): 0.47 m to infinity (Fixed focus at 1.4 m)5. Distortion Rate: Less than -92.2%6. Image Signal Processor (ISP): Built-in7. Frame Rate: 1920 x 1080 @ 30fps8. High Dynamic Range (HDR): Supported9. LED Flicker Mitigation (LFM): Supported10. Output Format: YUV422 @ 8-bit11. Serializer:--Model: MAXIM MAX96717F--I2C Address: 0x80 (8-bit address)12. Camera Interface: Fakra Z Code13. Operating Voltage: 9 ~ 12V PoC14. Operating Current: Less than 200mA @ 12V15. Operating Temperature: -40 ~ 85 deg C16. Protection Level: IP67Specification: Package Weight One Package Weight 0.08kgs / 0.19lb One Package Size 6cm * 6cm * 5cm / 2.36inch * 2.36inch * 1.97inch Qty per Carton 270 Carton Weight 23.00kgs / 50.71lb Carton Size 47cm * 38cm * 32cm / 18.5inch * 14.96inch * 12.6inch Loading Container 20GP: 466 cartons * 270 pcs = 125820 pcs40HQ: 1083 cartons * 270 pcs = 292410 pcs
£123.99
-
WAVESHARE For Raspberry Pi Series And Mainstream Jetson Boards ISX031 3MP MIPI Camera Module, 35301
1. Image sensor: Sony ISX031 2. CMOS size: 1/2.42 inch 3. Camera type: color 4. Effective pixels: about 3 million (1920 x 1536) 5. Diagonal size: 7.38 mm 6. Single pixel size: 3.0 microns x 3.0 microns 7. Aperture: F2.0 8. Focal length: 2.8 mm 9. Shutter type: rolling shutter 10. Infrared cut filter: built-in 11. Field of view (D x H x V): 123° x 98° x 75° 12. Focus method: fixed focus 13. Application scenarios: AI intelligent applications such as facial recognition, road marking detection, and license plate recognitionSpecification: Package Weight One Package Weight 0.02kgs / 0.05lb One Package Size 8cm * 8cm * 6cm / 3.15inch * 3.15inch * 2.36inch Qty per Carton 144 Carton Weight 4.00kgs / 8.82lb Carton Size 50cm * 38cm * 34cm / 19.69inch * 14.96inch * 13.39inch Loading Container 20GP: 412 cartons * 144 pcs = 59328 pcs40HQ: 958 cartons * 144 pcs = 137952 pcs
£93.99
-
Waveshare Waveshare IMX708 12MP Autofocus Camera 79.8-degree FOV Compatible with Raspberry Pi Series Boards, 35272
1. IMX708 sensor-based camera sensor module, compatible with Raspberry Pi series motherboards. Equipped with a 79.8-degree field of view (FOV), it balances sharp imaging with a wide coverage area to meet multi-scenario shooting needs. The module dimensions are identical to the Camera Module 3, and it is compatible with the libcamera library as well as Picamera2 and rpicam-apps built on top of it, allowing rapid development without extra debugging. It also features built-in autofocus to accurately capture clear images, combining professional performance with ease of use.2. Resolution: 11.9MP (4608 x 2592)3. Focus Method: I2C controller, supports autofocus4. CMOS Size: 7.4mm5. Aperture: F1.796. Focal Length: 4.7mm7. Distortion: Less than 1%Specification: Package Weight One Package Weight 0.02kgs / 0.05lb One Package Size 8cm * 5cm * 3cm / 3.15inch * 1.97inch * 1.18inch Qty per Carton 320 Carton Weight 7.50kgs / 16.53lb Carton Size 34cm * 42cm * 32cm / 13.39inch * 16.54inch * 12.6inch Loading Container 20GP: 583 cartons * 320 pcs = 186560 pcs40HQ: 1354 cartons * 320 pcs = 433280 pcs
£26.99
-
Waveshare Waveshare IMX708 Camera Sensor Module 11.9MP Compatible With The Raspberry Pi Camera Module 3 Baseboard, 35264
1. IMX708 Camera Sensor Module uses the same IMX708 sensor as the Raspberry Pi Camera Module 3 series. Featuring a 79.8-degree field of view (FOV), it balances sharp imaging with a wide coverage area, making it suitable for multi-scenario shooting requirements.2. The module can be used with the standard Camera Module 3 baseboard and also supports custom-developed baseboards. This significantly lowers integration barriers, allowing users to flexibly embed it into devices of various form factors and purposes for customized applications.3. Compatible with the libcamera library as well as Picamera2 and rpicam-apps built on top of it, enabling rapid development without extra debugging. It also features built-in autofocus to accurately capture clear images, combining professional performance with ease of use.4. Sensor: IMX7085. Resolution: 11.9 Megapixels (4608 x 2592)6. Sensor Size: 7.4mm (Diagonal)7. Focus Range: 10cm ~ infinity8. Focal Length: 4.7mm9. Aperture (F-stop): F1.7910. Distortion: Less than 1%11. IR Cut Filter: Built-inSpecification: Package Weight One Package Weight 0.02kgs / 0.04lb One Package Size 4cm * 3cm * 3cm / 1.57inch * 1.18inch * 1.18inch Qty per Carton 1584 Carton Weight 25.00kgs / 55.12lb Carton Size 50cm * 38cm * 35cm / 19.69inch * 14.96inch * 13.78inch Loading Container 20GP: 401 cartons * 1584 pcs = 635184 pcs40HQ: 930 cartons * 1584 pcs = 1473120 pcs
£20.99
-
Waveshare Waveshare Q43 NEO-F9P-15B Multi-Constellation Multi-Band GNSS RTK Centimeter-Level Positioning Module, 35110
1. This product is an integrated RTK smart positioning antenna module based on the NEO-F9P-15B. It integrates a high-precision RTK positioning engine, a helical antenna, and a geomagnetic sensor into a compact structure. The module supports multi-constellation and multi-band GNSS signal reception including GPS, BeiDou, GLONASS, Galileo, and QZSS, featuring dual-band RTK centimeter-level positioning capabilities. It provides stable and reliable high-precision positioning performance, making it suitable for applications such as smart robotics, shared mobility, precision agriculture, engineering surveying, handheld terminals, and vehicle navigation.2. Based on the NEO-F9P-15B high-precision positioning module, supporting dual-band RTK centimeter-level positioning.3. Integrated design combining the RTK positioning engine and helical antenna, with a compact structure for easy installation and seamless system integration.4. Built-in 3-axis geomagnetic sensor, ideal for compass, electronic compass, and heading assistance applications.5. Multi-constellation and multi-frequency support for GPS, BeiDou (BDS), GLONASS, Galileo, and QZSS satellite systems.6. Supports A-GNSS assisted positioning to reduce Time To First Fix (TTFF) using assistance data.7. Supports SBAS augmentation systems including WAAS, EGNOS, GAGAN, and QZSS SBAS.8. Supports u-center software configuration for easy setup of output protocols, update rates, and RTK operating modes.9. Wide voltage input design ranging from 3.3V to 16V, adapting to diverse power supply environments.Antenna Specifications:1. Signal Bands:--GPS: L1/L5--BDS: B1I/B1C/B2a--GLONASS: G1--Galileo: E1/E5a--QZSS: L1/L52. Characteristic Impedance: 50 ohms3. Polarization: RHCP (Right-Hand Circular Polarization)4. Coverage Angle: 360 degrees5. Peak Gain: 2.5 dBi6. VSWR: <= 2.07. Axial Ratio: <= 3 dBAmplifier Specifications:Gain: 23 dBNoise Figure: 1.5 dBOutput VSWR: <= 2.0System Parameters:1. Positioning Module: NEO-F9P-15B2. Geomagnetic Sensor: QMC5883P3. Operating Voltage: 3.3V - 16V4. Power Consumption: 500mW (Typical)5. PVT Single Point Accuracy:--Horizontal: 1.5m--Vertical: 2.0m6. SBAS Accuracy:--Horizontal: 1.0m--Vertical: 1.5m7. RTK Accuracy:--Horizontal: 1cm + 1ppm--Vertical: 1cm + 1ppm8. Time Accuracy (RMS): 30ns9. Velocity Accuracy (RMS): 0.05m/s10. Cold Start TTFF: < 30s11. Initialization Time: < 5s (Typical)12. Initialization Reliability: > 99.9%13. Data Update Rate: 25Hz (Max)14. Data Formats: RTCM 3.3; SPARTN 2.0.115. Communication Interfaces: I2C, UART (9.6k - 921.6kbps, default 38.4kbps)16. Physical Interface: GH1.25 8PINSpecification: Package Weight One Package Weight 0.05kgs / 0.12lb One Package Size 8cm * 8cm * 8cm / 3.15inch * 3.15inch * 3.15inch Qty per Carton 80 Carton Weight 5.10kgs / 11.24lb Carton Size 34cm * 34cm * 42cm / 13.39inch * 13.39inch * 16.54inch Loading Container 20GP: 549 cartons * 80 pcs = 43920 pcs40HQ: 1275 cartons * 80 pcs = 102000 pcs
£233.99
-
WAVESHARE IMX378-190 12.3MP Fisheye Lens Camera 190-Degree FOV Rolling Shutter For Raspberry Pi Series Boards, WAVESHARE 34709
1. Supports Raspberry Pi series, including Raspberry Pi 5 / 4B / 3B+ / 3A+ / Zero / Zero 2 W; CM 3 / 3+ / 4 / 5 requires a compatible carrier board for use 2. 12.3-megapixel high-definition resolution for sharper image quality; fisheye lens with a wide 190° field of view 3. Image sensor: IMX378 4. CMOS size: 1/2.3 inch 5. Camera type: color 6. Resolution: 12.3 megapixels (4056 x 3040) 7. Shutter type: rolling shutter 8. Aperture: F2.4 9. Distortion: less than 58% 10. Field of view: 190° 11. Focal length: 6.5 mm 12. Focus type: fixed focusSpecification: Package Weight One Package Weight 0.03kgs / 0.07lb One Package Size 6cm * 6cm * 4cm / 2.36inch * 2.36inch * 1.57inch Qty per Carton 384 Carton Weight 13.00kgs / 28.66lb Carton Size 50cm * 38cm * 34cm / 19.69inch * 14.96inch * 13.39inch Loading Container 20GP: 412 cartons * 384 pcs = 158208 pcs40HQ: 958 cartons * 384 pcs = 367872 pcs
£48.99
-
WAVESHARE WAVESHARE 35106 TOF Laser Range Sensor Based On D-TOF Single-Point Laser Sensor UART Communication Support, 0.02-5m
1. Typical measurement range: 0.02m - 5m2. Error: ±(1% - 3%)3. Field of View (FOV): 3° ± 0.5°4. Refresh rate: 30Hz (This parameter supports batch customization, with a maximum of 90Hz)5. Anti-environmental light capability: 100K Lux6. Operating temperature: -20°C to +70°C7. Operating humidity: 35% to 80% RH8. Laser safety level: LASER CLASS 19. Wavelength: 940nm10. Communication interface: UART11. Communication baud rate: 115.2Kbps12. Supply voltage: 4V - 5.6V13. Communication level: 3.3V14. Product power consumption: 100mW - 140mW15. Storage temperature: -40°C to +80°C16. Shell material: PC17. Size: about 3.55 x 1.62 x 1.35 cm18. Weight: about 3.6g19. Packaging list: TOF MINIF Range Sensor (B) x 1, MX1.25 4PIN connector cable 100mm x 1Specification: Package Weight One Package Weight 0.07kgs / 0.16lb One Package Size 7cm * 6cm * 4cm / 2.76inch * 2.36inch * 1.57inch Qty per Carton 288 Carton Weight 22.00kgs / 48.50lb Carton Size 50cm * 38cm * 30cm / 19.69inch * 14.96inch * 11.81inch Loading Container 20GP: 467 cartons * 288 pcs = 134496 pcs40HQ: 1086 cartons * 288 pcs = 312768 pcs
£9.99
-
WAVESHARE WAVESHARE IMX477 IR-CUT 12.3MP Camera For Raspberry Pi / Jetson / RDK Series Boards, 34816
Sensor:1. Model: Sony IMX4772. 12.3 megapixels: 4056 x 30403. CMOS diagonal length: 7.9 mm4. Pixel size: 1.55 μm (H) x 1.55 μm (V)5. Shutter type: Rolling shutterLens:1. Aperture (F): 2.82. Focal Length (EFL): 2.7 mm3. Field of View (FOV): 113 degrees (D)4. Distortion: Less than -1.5%Features:1. Equipped with Sony IMX477 image sensor, it delivers high-resolution, clear images up to 12.3 MP with rich detail capture2. Features a hardware-integrated IR-CUT switching mechanism that restores natural colors without color cast during the day; when paired with an infrared illuminator (not included), it supports night vision imaging to meet all-weather monitoring needs3. Equipped with a 113-degree wide-angle lens and rolling shutter design, providing a wider field of view and imaging coverage in confined spaces4. Compatible with Raspberry Pi series (e.g., 4B, 5, Zero 2 W, CM4/CM5), for NVIDIA Jetson series (driver support required), and open-source hardware development boards such as the RDK X55. Includes two types of flexible FPC cables 15-pin to 22-pin and 22-pin for quick and easy connection to motherboards with different connector interfaces6. Operating voltage: 3.3V7. Application scenarios: AI applications such as facial recognition, road marking recognition, and license plate recognition8. Dimensions: Approximately 3.8 x 2.5 cmSpecification: Package Weight One Package Weight 0.06kgs / 0.14lb One Package Size 9cm * 6cm * 4cm / 3.54inch * 2.36inch * 1.57inch Qty per Carton 200 Carton Weight 12.80kgs / 28.22lb Carton Size 38cm * 32cm * 20cm / 14.96inch * 12.6inch * 7.87inch Loading Container 20GP: 1096 cartons * 200 pcs = 219200 pcs40HQ: 2545 cartons * 200 pcs = 509000 pcs
£73.99
-
WAVESHARE WAVESHARE TOF MINIS Laser Range Sensor, Based On Time-of-Flight (TOF) Technology, Built-in Controller And Ranging Algorithm, RS485 Communication Support, 35108
1. Typical measurement range: 0.02m - 5m2. Ambient light tolerance: 100,000 lux3. Field of view: 1.48 degrees4. Refresh rate: 30 Hz5. Protection rating: IP686. Operating temperature: -20 to 70 degrees Celsius7. Operating humidity: 35%-80% RH8. Laser safety class: LASER CLASS 1 (IEC 60825-1: 2014)9. Wavelength: 940 nm10. Communication Interface: RS48511. Communication Baud Rate: 115,20012. Supply Voltage: 4V - 5.6V13. Power Consumption: 100 mW - 140 mW14. Average Current/Peak Current: 25 mA/26 mA15. Housing Material: PC16. Storage Temperature: -40 to 80 degrees Celsius17. Weight: Approx. 15.8g18. Dimensions: Approx. 2.95 x 1.8cm; Cable Length: Approx. 60cmSpecification: Package Weight One Package Weight 0.04kgs / 0.10lb One Package Size 10cm * 8cm * 4cm / 3.94inch * 3.15inch * 1.57inch Qty per Carton 100 Carton Weight 5.00kgs / 11.02lb Carton Size 42cm * 34cm * 20cm / 16.54inch * 13.39inch * 7.87inch Loading Container 20GP: 933 cartons * 100 pcs = 93300 pcs40HQ: 2167 cartons * 100 pcs = 216700 pcs
£18.99
-
WAVESHARE WAVESHARE MINI Laser Range Sensor, Based On Time-of-Flight Technology, Built-in Controller And Ranging Algorithm, UART Communication Support, 35107
1. Typical ranging range: 0.02m - 4m2. Error: +/- (1% - 3%)3. Field of View (FOV): 25 - 30 degrees4. Refresh rate: 30Hz5. Ambient light immunity: 20K Lux6. Operating temperature: -20 to 70 degrees Celsius7. Operating humidity: 35% - 80% RH8. Laser safety class: LASER CLASS 1 (IEC 60825-1: 2014)9. Wavelength: 940nm10. Communication interface: UART11. Baud rate: 11520012. Data bits: 813. Stop bit: 114. Parity: None15. Supply voltage: 4V - 5.6V16. Power consumption: 100mW - 140mW17. Average/Peak current: 25mA/26mA18. Housing material: PC19. Storage temperature: -40 to 80 degrees Celsius20. Weight: Approx. 3g21. Dimensions: Approx. 17.37 x 13 x 6.88mmSpecification: Package Weight One Package Weight 0.03kgs / 0.07lb One Package Size 7cm * 6cm * 2cm / 2.76inch * 2.36inch * 0.79inch Qty per Carton 200 Carton Weight 6.80kgs / 14.99lb Carton Size 36cm * 30cm * 30cm / 14.17inch * 11.81inch * 11.81inch Loading Container 20GP: 823 cartons * 200 pcs = 164600 pcs40HQ: 1910 cartons * 200 pcs = 382000 pcs
£5.99
-
Waveshare Waveshare 24896 TFmini-i Industrial Lidar Ranging Sensor 12m Ranging Distance, IP65 Protection, RS485 Industrial Interface
1. TFmini-i is a single-point ranging LiDAR upgraded from the TFmini-S. It features optimized enhancements in communication interfaces and input voltage to meet the demands of various industrial scenarios. Based on the ToF (Time of Flight) principle, the product delivers stable, precise, and highly sensitive measurement performance.2. Working Principle: TFmini-i operates on the ToF (Time of Flight) principle. Specifically, the device periodically emits near-infrared modulated light waves, which reflect back upon hitting an object. The device calculates the relative distance between itself and the target by measuring the phase difference of the round-trip modulated waves to determine the time of flight.3. Supports wide voltage input and RS-485 interface.4. Application Scenarios: Pedestrian detection / Vehicle detection / Altimeter / Robotics. SpecificationsPerformance Parameters1. Ranging Range:--0.1m to 12m at 90% reflectivity (Indoor 0Klux)--0.1m to 7m at 10% reflectivity (Indoor 0Klux)--0.1m to 12m at 90% reflectivity (Outdoor 70Klux)--0.1m to 7m at 10% reflectivity (Outdoor 70Klux)2. Accuracy:--plus or minus 6cm (0.1m to 6m)--plus or minus 1% (6m to 12m)3. Distance Resolution: 1cm4. Frame Rate: 1 to 40Hz5. Ambient Light Immunity: 70Klux6. Operating Temperature: minus 20 to 60 degrees Celsius7. Enclosure Rating: IP65Optical parameters:1. Light source: VCSEL2. Center wavelength: 850nm3. Eye safety: Class 1 (IEC60825)4. Field of View (FOV): 2 degreesElectrical parameters：1. Supply voltage: DC 7V–30V2. Average current: less than or equal to 65mA at 12V3. Power consumption: less than 0.8W at 12V4. Peak current: 100mA at 12V5. Communication interface: RS485Other:1. Dimensions: 50mm x 34mm x 41mm (L x W x H)2. Housing material: ABS/PC/PMMA3. Storage temperature: minus 30 to 75 degrees Celsius4. Weight: 52g (including cable)5. Cable length: 70cmSpecification: Package Weight One Package Weight 0.19kgs / 0.43lb One Package Size 12cm * 8cm * 5cm / 4.72inch * 3.15inch * 1.97inch Qty per Carton 100 Carton Weight 20.10kgs / 44.31lb Carton Size 42cm * 30cm * 35cm / 16.54inch * 11.81inch * 13.78inch Loading Container 20GP: 604 cartons * 100 pcs = 60400 pcs40HQ: 1403 cartons * 100 pcs = 140300 pcs
£104.99
-
Waveshare Waveshare OV4689 4MP USB Camera 92-Degree FOV, Supports Type-C Port And SH1.0 4PIN Header, 34767
Specification: Package Weight One Package Weight 0.04kgs / 0.10lb One Package Size 8cm * 8cm * 5cm / 3.15inch * 3.15inch * 1.97inch Qty per Carton 100 Carton Weight 5.00kgs / 11.02lb Carton Size 37cm * 30cm * 30cm / 14.57inch * 11.81inch * 11.81inch Loading Container 20GP: 800 cartons * 100 pcs = 80000 pcs40HQ: 1859 cartons * 100 pcs = 185900 pcs
£19.99
-
12V Full Auto Water Level Control Switch Module Water Tank Liquid Level Sensor Automatic Pumping Device, 12V
1. Wide range of applications 2. Easy to operate 3. Small size 4. Stable performance 5. Voltage specification: 12V 6. Module size: 5 x 4.4 x 1.8cm (manual measurement) 7. Net weight: 24g 8. Module function: When the water level is lower than the B probe, the water is automatically pumped. 9. Stop pumping when the water level reaches the C probe. 10. The A/B/C water level sensing line can be used with ordinary wires, and the wire ends are exposed to 5CM. Automatically pump water when the water level is below point B 11. Stop pumping when the water level is above point CSpecification: Package Weight One Package Weight 0.04kgs / 0.10lb One Package Size 8cm * 6cm * 2cm / 3.15inch * 2.36inch * 0.79inch Qty per Carton 300 Carton Weight 11.50kgs / 25.35lb Carton Size 52cm * 42cm * 42cm / 20.47inch * 16.54inch * 16.54inch Loading Container 20GP: 290 cartons * 300 pcs = 87000 pcs40HQ: 674 cartons * 300 pcs = 202200 pcs
£4.99 £1.99
-
5V Full Auto Water Level Control Switch Module Water Tank Liquid Level Sensor Automatic Pumping Device, 5V Water Tank Liquid Level Sensor
1. Wide range of applications 2. Easy to operate 3. Small size 4. Stable performance 5. Voltage specification: 5V 6. Module size: 5 x 4.4 x 1.8cm (manual measurement) 7. Net weight: 24g 8. Module function: When the water level is lower than the B probe, the water is automatically pumped. 9. Stop pumping when the water level reaches the C probe. 10. The A/B/C water level sensing line can be used with ordinary wires, and the wire ends are exposed to 5CM. Automatically pump water when the water level is below point B 11. Stop pumping when the water level is above point CSpecification: Package Weight One Package Weight 0.04kgs / 0.08lb One Package Size 8cm * 6cm * 2cm / 3.15inch * 2.36inch * 0.79inch Qty per Carton 300 Carton Weight 11.50kgs / 25.35lb Carton Size 52cm * 42cm * 42cm / 20.47inch * 16.54inch * 16.54inch Loading Container 20GP: 290 cartons * 300 pcs = 87000 pcs40HQ: 674 cartons * 300 pcs = 202200 pcs
£4.99 £1.99
-
Waveshare Waveshare IMX291 2MP IR-CUT Camera Fixed-Focus 83-Degree Diagonal FOV, Rolling Shutter, 34494
The IMX291-83 IR-CUT Camera features the IMX291 starlight-grade image sensor and is compatible with the full range of Raspberry Pi boards and Compute Modules. It comes standard with an 83-degree lens and 2-megapixel high-definition resolution. Equipped with an onboard IR-CUT dual-filter switcher, it allows for one-touch switching between full-color daytime mode and infrared night vision mode via an onboard DIP switch, ensuring clear and stable imaging day and night.Specifications:1. Image Sensor: IMX2912. CMOS Size: 1/2.8 inch3. Resolution: 2 Megapixels (1920 × 1080)4. Aperture: F2.05. Focal Length: 3.95mm6. Diagonal Field of View: 83 degrees7. Camera Type: Color8. Focus Type: Fixed focus9. Distortion: Less than 33%10. Shutter Type: Rolling shutterSpecification: Package Weight One Package Weight 0.06kgs / 0.13lb One Package Size 7cm * 7cm * 5cm / 2.76inch * 2.76inch * 1.97inch Qty per Carton 180 Carton Weight 11.00kgs / 24.25lb Carton Size 47cm * 37cm * 30cm / 18.5inch * 14.57inch * 11.81inch Loading Container 20GP: 511 cartons * 180 pcs = 91980 pcs40HQ: 1186 cartons * 180 pcs = 213480 pcs
£56.99
-
Waveshare Waveshare 1MP GMSL Camera Module Automotive-grade Image Sensor, Built-in ISP, AA Lens, IP67 Protection Degree, 34552
1. The GMSL-1MP-Camera-A camera module adopts a 1MP automotive-grade CMOS image sensor and integrates the MAXIM MAX96701 GMSL serializer. It includes a professionally calibrated image signal processor (ISP), delivering clear and stable image quality. The entire unit features an IP67-rated case and comes with an AA lens, and each unit is precisely focused and glue-secured before shipment, making it well-suited for automotive and other demanding applications.Specifications:1. Sensor:--Model: 1.3MP RGGB--Resolution: 1280 × 960--CMOS Size: 1/3.55 inch--Pixel Size: 3.0 μm × 3.0 μm2. Lens: Field of View: 196-degree (H) × 151-degree (V)3. ISP: Built-in4. Frame Rate: 1280 × 960 at 30 fps5. Output Format: YUV422 (8-bit)6. Serializer:--Model: MAXIM MAX96701--I2C Address: 0x80 (8-bit address)7. Camera Interface: TE Fakra (C Code)8. Operating Voltage: 9 ~ 12V PoC9. Operating Current: Less than 150 mA at 12V10. Operating Temperature: -40 ~ 85 degrees Celsius11. Protection Rating: IP67Specification: Package Weight One Package Weight 0.08kgs / 0.19lb One Package Size 6cm * 6cm * 5cm / 2.36inch * 2.36inch * 1.97inch Qty per Carton 270 Carton Weight 23.00kgs / 50.71lb Carton Size 47cm * 38cm * 32cm / 18.5inch * 14.96inch * 12.6inch Loading Container 20GP: 466 cartons * 270 pcs = 125820 pcs40HQ: 1083 cartons * 270 pcs = 292410 pcs
£80.99
-
Industrial 4-Ch DC Monitoring Module, 16-Bit High-Precision Acquisition, Supports Voltage And Current Measurement, Modbus RTU Protocol, 33931
1. Support setting of device address (1 - 255) to enable cascading of multiple devices via RS485 bus2. Onboard voltage stabilizing chip, supporting a wide voltage range of 7V - 36V3. Onboard integrated power isolation, providing stable isolated voltage. The isolated terminals do not require additional power supply4. Onboard optocoupler isolation, capable of signal isolation, with high reliability and strong anti-interference5. Onboard self-recovery fuse and TVS (Transient Voltage Suppression Diode), effectively suppressing surge voltages and transient peak voltages in the circuit, preventing overcurrent, overvoltage, lightning and static electricity6. Onboard 0.002 ohm 1% sampling resistor, 16-bit high-precision acquisition, capable of measuring bidirectional current7. The maximum measurement voltage is supported up to 36V, the maximum measurement current is supported up to 8A, and direct measurement of power is supported8. Rail-mounted enclosure design, supporting stacking combination, easy installation, and safer to use9. Three external LED indicators, facilitating viewing of MCU status and signal transmission/reception statusParameters1. Communication interface: RS4852. Communication baud rate: 4800, 9600, 19200, 38400, 57600, 115200, 128000, 2560003. Default communication format: 9600, N, 8, 14. Modbus protocol: standard Modbus RTU protocol5. Power supply voltage: DC 7V - 36V6. Sampling resistance: 0.002 ohm, 1%7. Measurement range: voltage: 0 - 36V, current: ±8A8. Resolution: 0.8mAPackaging list: - Modbus RTU DC Monitor x 1- Power adapter x 1- Screwdriver x 1Specification: Package Weight One Package Weight 0.16kgs / 0.36lb One Package Size 16cm * 11cm * 6cm / 6.3inch * 4.33inch * 2.36inch Qty per Carton 48 Carton Weight 9.00kgs / 19.84lb Carton Size 46cm * 38cm * 34cm / 18.11inch * 14.96inch * 13.39inch Loading Container 20GP: 448 cartons * 48 pcs = 21504 pcs40HQ: 1041 cartons * 48 pcs = 49968 pcs
£27.99
-
Waveshare Environment 6 In 1 Gas Sensor Module Supports UART Control Interface, Waveshare 34169
1. Integrated comprehensive compound (IAQ), carbon monoxide (CO), organic compounds (TVOC), formaldehyde (HCHO), temperature and humidity detection2. Supports UART interface communication, with a baud rate of 9600bps, 8-bit data, 1 stop bit, no parity bit3. Small size, low cost, high value for money4. Supports UART control interface, can be connected to main control boards such as Raspberry Pi / Pico / Arduino / ESP325. Widely applied, suitable for environmental monitoring, smart home appliances, indoor detection, automotive electronics, etcParameters1. Working voltage: 5V2. Communication interface: UART3. Logic voltage: 3.3V4. Baud rate: 9600bps5. Working current: 6.5mA6. Working humidity: more than 15%RH7. Working temperature: -40 °C - +55 °C8. Fixed aperture: 2.0mm9. Measurement range: formaldehyde: 0 - 1ppm; organic matter: 0 - 5ppm; carbon monoxide: 0 - 100ppm10. Resolution: formaldehyde: 0.001ppm (Effective detection value: 0.015ppm); organic matter: 0.001ppm (Effective detection value: 0.050ppm); carbon monoxide: 0.001ppm (Effective detection value: less than 8ppm)11. Response time: formaldehyde: T10: less than 5s; T90: less than 90s (Gas injection measurement); organic matter: T10: less than 3s; T90: less than 120s (Isobutylene gas injection measurement); carbon monoxide: T10: less than 3s; T90: less than 15s (Gas injection measurement)12. Accuracy error: formaldehyde: 0 - 0.15ppm (±0.02ppm); 0.16ppm+ (less than ±2% FS); organic matter: 0 - 0.2ppm (±0.05ppm); 0.2ppm+ (less than ±2% FS); carbon monoxide: 0 - 8ppm (±2.5ppm); 8ppm+ (less than ±1% FS)13. Size: about 2.3 x 2.55 x 0.95 cmPackaging list:- Environment X6 Sensor x 1- MX1.25 4PIN connection cable, about 200mm in length x 1Specification: Package Weight One Package Weight 0.02kgs / 0.04lb One Package Size 6cm * 6cm * 4cm / 2.36inch * 2.36inch * 1.57inch Qty per Carton 360 Carton Weight 7.00kgs / 15.43lb Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch Loading Container 20GP: 438 cartons * 360 pcs = 157680 pcs40HQ: 1018 cartons * 360 pcs = 366480 pcs
£43.99
Sie haben 24 von 49 Produkten gesehen
