Resultados de la búsqueda de "electronics"

1. Features an Armv8-M STAR-MC1 MCU with a clock speed of up to 480 MHz2. Supports 2.4 GHz Wi-Fi (802.11 b/g/n/ax) and Bluetooth 5.4 (Bluetooth LE), with an onboard antenna3. Features 640 KB of SRAM and 64 KB of ROM, with 16 MB of PSRAM in a stacked package and 8 MB of external Flash4. On-board 1.75-inch capacitive touch HD AMOLED display with 466 x 466 resolution and 16.7 million colors, capable of clearly displaying color images5. Built-in CO5300 driver chip and CST9217 capacitive touch chip, communicating via QSPI and I2C interfaces respectively, without occupying excessive interface pin resources6. Features a Type-C interface, enhancing user convenience and device compatibility7. On-board QMI8658 six-axis inertial measurement unit (3-axis accelerometer, 3-axis gyroscope), capable of detecting motion posture, step counting, and other functions8. On-board PCF85063 RTC chip, providing precise timekeeping and automatic leap year handling9. On-board PWR and KEY side buttons with customizable functions, facilitating the development of custom button features10. On-board 3.7V MX1.25 lithium battery charging and discharging interface11. On-board 8-pin 2.54mm pitch female header, exposing 5 GPIO pins and reserving 5 IO pads for external devices and debugging, enabling flexible configuration of peripheral functions12. On-board Micro SD card slot for flexible storage expansion and fast data transfer, suitable for data logging and media playback, simplifying circuit design13. Features an AMOLED display with higher contrast, wider viewing angles, rich colors, and fast response times for superior visual performance, while offering advantages such as a slim design, low power consumption, and flexibilityDisplay specifications1. Display panel: AMOLED2. Display size: 1.75 inches3. Display resolution: 466 x 466 pixels4. Display colors: 16.7M5. Display brightness: 700 cd/square meter6. Contrast ratio: 100,000:17. Communication interface: QSPI8. Driver IC: CO53009. Touch: supported10. Touch IC: CST9217Standard packaging list:- T5-E1-Touch-AMOLED-1.75 x 1- 8-ohm 2W speaker x 1GPS packaging list:- T5-E1-Touch-AMOLED-1.75-G (with GPS) x 1- 8-ohm 2W speaker x 1- GNSS ceramic antenna x 1Specification: Package Weight One Package Weight 0.10kgs / 0.23lb One Package Size 10cm * 8cm * 4cm / 3.94inch * 3.15inch * 1.57inch Qty per Carton 160 Carton Weight 18.00kgs / 39.68lb Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch Loading Container 20GP: 438 cartons * 160 pcs = 70080 pcs40HQ: 1018 cartons * 160 pcs = 162880 pcs

Leer Más Menos

Features1.Pixels: 5 megapixel2.Resolution: 2592x19443.Sensor: OV5640 3.1 1.4um x 1.4um pixel with OmniBSI technology, high sensitivity, low crosstalk, low noise 3.2 Automatic image control functions: AEC, AWB, ABF, ABLC, etc. 3.3 Image quality controls: color saturation, hue, gamma, sharpness, lens correction, etc. 3.4 Supports image scaling, panning, windowing, etc.4.Lens: 4.1 CCD size: 1/4inch 4.2 Aperture (F): 2.8 4.3 Focal Length: 2.8mm 4.4 Diagonal: 63 degree5.Output Formats: 5.1 YUV(422/420)/YCbCr422 5.2 RGB565/555/444 5.3 CCIR656 5.4 RAW RGB 5.5 Compressed Data6.Operating Voltage: 3.3V7.Control Interface: SCCB (I2C compatible)8.Data Interface: DVP 8-bit9.Dimension: 35.70mm × 23.90mmSpecification: Package Weight One Package Weight 0.01kgs / 0.03lb One Package Size 6cm * 4cm * 1cm / 2.36inch * 1.57inch * 0.39inch Qty per Carton 4000 Carton Weight 15.00kgs / 33.07lb Carton Size 60cm * 40cm * 40cm / 23.62inch * 15.75inch * 15.75inch Loading Container 20GP: 277 cartons * 4000 pcs = 1108000 pcs40HQ: 644 cartons * 4000 pcs = 2576000 pcs

Leer Más Menos

Features:1. Large LCD, easy-to-read 3.5-inch high-definition display.2. Durable protective shell can prevent impact, friction and collision.3. Non-contact AC voltage detection, top sensor probe design, more securely identify AC voltage.4. The high-resolution large screen can display 3 test results on the screen, including voltage, frequency, and analog bars.parameter:1. Dimensions: 143.4 x 70.9 x 15.7mm2. Display: 9999 times3. Screen: 3.5 inches4. Resolution: 0.11ohms5. S10 power supply: 1.5V (AAA) x 2 (not included)6. S11 power supply: 800 mA lithium battery7. Diode: automatically recognize the diode when it is lower than 3.0V8. DC voltage: 0.8V-620V +/-(0.5%+3), resolution: 0.001V9. AC voltage: 2.2V-620V +/-(0.5%+5), resolution: 0.001V10. Resistance: 1Ω-999.9ohms +/-(2.0%+5), 1kohms-60Mohms +/-(1.0%+3)11. V-Alert (non-contact voltage detection): buzzer alarm sound，on-site inspection: alarm buzzer, LCD screen display stripes12. Continuity: If the resistance is less than 30ohms, the buzzer will sound13. Frequency:- 1Hz-1000Hz +/-(1.0%+5) (ACV:2V-10V); resolution: 0.001Hz- 1KHz-60KHz +/-(1.0%+5) (ACV:10V-620V); resolution: 0.001HzPacking list:S10:S10 Multimeter x 1Test cable x 1Manual x1S11:S11 Multimeter x 1Test cable x 1Type-C charging cable x 1EVA cloth bag x 1Protective shell x 1Manual x1Note: The actual product is subject to the title model, the model machine of the picture is only for effect referenceSpecification: Package Weight One Package Weight 0.32kgs / 0.71lb One Package Size 17cm * 10cm * 4.5cm / 6.69inch * 3.94inch * 1.77inch Qty per Carton 80 Carton Weight 28.00kgs / 61.73lb Carton Size 47cm * 42cm * 35cm / 18.5inch * 16.54inch * 13.78inch Loading Container 20GP: 385 cartons * 80 pcs = 30800 pcs40HQ: 896 cartons * 80 pcs = 71680 pcs

Leer Más Menos

1. Power Supply: NFC wireless power transfer 2. Gray Scale Levels: 2 3. Display Colors: Red, Yellow, Black, White 4. Refresh Time: 16 seconds (excluding data transmission time) 5. Dot Pitch: 0.135 x 0.135 (mm) 6. Viewing Angle: Greater than 170 degrees7. Resolution: 296 x 128 pixels 8. Display Size: Approx. 66.89 x 29.05 mm9. Dimensions: Approx. 8.75 x 4.77 x 1.27 cmFeatures:1. Uses a passive NFC solution with no built-in battery, eliminating the need for complicated wiring2. When the display needs to be refreshed, simply bring an NFC-enabled smartphone or card reader close to the e-ink screen to wirelessly power it and update the display content3. Suitable for retail price tags, asset and equipment tags, electronic shelf labels, and conference name tags, among others4. Eco-friendly and energy-efficient; easy to operate via an Android app5. ABS housing; sleek, lightweight, and aesthetically pleasingSpecification: Package Weight One Package Weight 0.08kgs / 0.19lb One Package Size 12cm * 7cm * 3cm / 4.72inch * 2.76inch * 1.18inch Qty per Carton 100 Carton Weight 8.50kgs / 18.74lb Carton Size 37cm * 25cm * 28cm / 14.57inch * 9.84inch * 11.02inch Loading Container 20GP: 1029 cartons * 100 pcs = 102900 pcs40HQ: 2390 cartons * 100 pcs = 239000 pcs

Leer Más Menos

1. Screen: 1.14 inches2. Power supply voltage: 250mAh rechargeable lithium battery3. Charging specifications: USB Type-C, 5V/1A4. Accurately measure tiny components and dense pins, unique design, gold-plated tweezers5. Integrates multi-functional measurements, accurately covers resistance, capacitance, inductance, diodes, etc., and uses cutting-edge technology to ensure accurate and reliable data6. Lightweight design, compact size, easy to carry, and convenient for business trips7. Brass gold-plated material, straight and curved tweezers heads can be replaced, high hardness, more durable, adapt to different application scenarios, and provide more accurate measurement stabilitySupport data retention, automatically record data and generate EXCEL tables, view recorded data on the computer8. Equipped with a 1.14-inch high-definition color display, the interface is clear and intuitive, data reading is effortless, making your test work smoother and unimpeded9. Automatically identify components, display primary and secondary parameters at the same time, ESR (equivalent resistance); D value (loss tangent); Q value (quality factor); X value (reactance); Z value (total impedance)10. Supports three test frequencies of 100Hz, 1kHz, and 10kHz, and 0.3V and 0.6Vrms effective value test levels, making the test results comprehensive and accurate11. Weight: 41g12. Size: 28x19x150mmPacking list:1. Smart tweezer bridge2. Gold-plated tweezers bent feet (a pair)3. Iron sheet (with adhesive backing)4. USB data cable5. User manual6. Packing boxSpecification: Package Weight One Package Weight 0.17kgs / 0.38lb One Package Size 20cm * 7cm * 7cm / 7.87inch * 2.76inch * 2.76inch Qty per Carton 100 Carton Weight 18.50kgs / 40.79lb Carton Size 56cm * 41cm * 34cm / 22.05inch * 16.14inch * 13.39inch Loading Container 20GP: 341 cartons * 100 pcs = 34100 pcs40HQ: 793 cartons * 100 pcs = 79300 pcs

Leer Más Menos

1. 4.3-inch IPS ultra-high definition screen, easy to use2. Built-in high-capacity lithium battery, long battery life3. Using the core of a powerful FPGA + MCU + high-speed ADC hardware architecture system waveforms smooth and clear4. Measurement of millivolt level of weak signals, support for 20M bandwidth limits5. Powerful waveform computing capabilities, real-time addition, subtraction, multiplication and division operations, in-depth analysis and processing of complex signals6. Real-time capture and display the changes in a variety of measurement parameters, forming a clear and concise data trend graph, but also has the ability to retain up to 5 groups of measurement data, at a glance7. Double current fuse, to prevent burning the meter more safely8. Easy to manage oscillometric images, can be connected to a computer via USB cable for secondary analysis9. Lightweight, one-handed, easy to put into a pocket or toolkit, convenient to carryBasic parameters:1. Screen material: surface tempered glass + glass GLASS material touch screen + IPS color screen2. Backlight: backlight brightness can be set3. Power supply: Type-C (5V/2A)4. Battery: 4000mAh li-ion battery5. Size: 145 x 98 x 35mm6. Weight: 360gOscilloscope parameters:1. Channel: dual-channel2. Bandwidth: 50MHz3. Real-time sampling rate: 250MSa / s4. Memory depth: up to 64kByte5. Time base range: 10ns/div-10s/div6. Vertical sensitivity: 10mv/div-10v/div7. Waveform display mode: YT / XY / scrolling8. Vertical resolution: 8 bits9. Input impedance: ΙΜΩ10. Bandwidth limitation: support 20MHz limitation11. Probe attenuation factor: 1x/10x12. Input coupling: AC/DC13. Trigger type: rising edge/falling edge14. Maximum voltage: +/-400V15. Trigger level range: 8 cells (positive and negative)16. Trigger mode: automatic / normal / single17. Memory space: 13M18. Measurement data: period, frequency, peak-to-peak value, maximum value, minimum value, average value, RMS value, amplitude, duty cycle and pulse widthSignal generator parameters:1. Different waveform output frequency: sine wave: 10MHz, other waveforms: 5MHz2. Waveform frequency: 0-10ΜΗz3. Waveform amplitude: 0.1V-3.0V4. Duty cycle of square wave: 0-100 percentMultimeter parameters:1. DC voltage: 1.9999V/19.999V/199.99V/1000.0V2. AC voltage: 1.9999V/19.999V/199.99V/760.0V3. DC current: 19.999mA/199.99mA/1.9999A/9.999A4. AC current: 19.999mA/199.99mA/1.9999A/9.999A5. Resistance: 19.999ΜΩ/1.9999ΜΩ/199.99ΚΩ/19.999ΚΩ/1.9999ΚΩ/199.99Ω6. Capacitance: 999.9uF/99.99uF/9.999uF/999.9nF/99.99nF/9.999nF9.999mF/99.99mF7. Temperature: -55-1300 degrees celsius/-67-2372 degrees fahrenheitSpecification: Package Weight One Package Weight 0.97kgs / 2.14lb One Package Size 24cm * 14cm * 7cm / 9.45inch * 5.51inch * 2.76inch Qty per Carton 20 Carton Weight 21.00kgs / 46.30lb Carton Size 49cm * 31cm * 39cm / 19.29inch * 12.2inch * 15.35inch Loading Container 20GP: 450 cartons * 20 pcs = 9000 pcs40HQ: 1044 cartons * 20 pcs = 20880 pcs

Leer Más Menos

1. Resolution: 800 × 8002. Display interface: DSI3. Display panel: IPS4. Viewing angle: 170 degrees5. Touch type: capacitive touch6. Touch points: ten-point touch7. Touch interface: I2C8. Touch panel: tempered glass panel9. Touch panel process: full lamination10. Application scenarios: smart home, automotive equipment, consumer electronics, industrial equipment, etc.11. Screen size: about 3.4 inches12. Size ：approx. 11.5 x 1.7cmFeatures:1. IPS display panel with good display performance and wide viewing angle up to 170 degrees2. Can support 10-point touch, the actual number of touch points with the software system3. Tempered glass panel, hardness up to 6H4. Screen full lamination, good display, dustproof5. Backlight brightness can be adjusted by software6. Support Raspberry Pi OS, ten-point touch, need to install the driver7. Support Pi 4B/3B+/3A+, some CM3/3+/4 expansion boards need to purchase additional adapter cableSpecification: Package Weight One Package Weight 0.20kgs / 0.45lb One Package Size 13cm * 13cm * 2cm / 5.12inch * 5.12inch * 0.79inch Qty per Carton 146 Carton Weight 30.00kgs / 66.14lb Carton Size 50cm * 50cm * 60cm / 19.69inch * 19.69inch * 23.62inch Loading Container 20GP: 177 cartons * 146 pcs = 25842 pcs40HQ: 412 cartons * 146 pcs = 60152 pcs

Leer Más Menos

1. Supports up to 10-point touch; actual touch points depend on the software system2. Tempered glass panel with 6H hardness3. Backlight brightness adjustable via software4. Full-laminated screen for high clarity and dust resistance5. IPS display panel delivers excellent performance with a wide 178° viewing angle6. This product defaults to portrait orientation with a resolution of 480 x 1920 (H x V). Landscape display can be enabled by modifying software settings7. Size: about 24.5 x 6.8cmPackage contents:- 8.8-DSI-TOUCH-A touchscreen x 1- MIPI-DSI-Cable-12cm x 1- MX1.25 2-pin to 2.54mm 3-pin adapter cable x 1- FFC cable 22-pin 200mm (opposite direction) x 2- MX1.25 2-pin to MX1.25 4-pin adapter about 150mm x 1- Screw set x 1Specification: Package Weight One Package Weight 0.30kgs / 0.67lb One Package Size 28cm * 12cm * 4cm / 11.02inch * 4.72inch * 1.57inch Qty per Carton 36 Carton Weight 12.00kgs / 26.46lb Carton Size 50cm * 38cm * 30cm / 19.69inch * 14.96inch * 11.81inch Loading Container 20GP: 467 cartons * 36 pcs = 16812 pcs40HQ: 1086 cartons * 36 pcs = 39096 pcs

Leer Más Menos

1. The RP2350B microcontroller chip, designed based on the Raspberry Pi architecture2. A unique dual-core, dual-architecture design featuring a dual-core ARM Cortex-M33 processor and a dual-core Hazard3 RISC-V processor, both operating at up to 150MHz, allowing users to switch flexibly between the two architectures3. Features 520KB of SRAM, 16MB of on-board on-chip Flash, and 2MB of PSRAM4. Features a Type-C interface, eliminating the need to worry about orientation when plugging in5. Features a 4.3-inch on-board capacitive touchscreen LCD with 800 × 480 resolution and 65K colors6. Supports I2C interface control for capacitive touch, 5-point touch, and interrupts7. On-board resources include CAN, RS485, I2C interfaces, and isolated digital I/O8. On-board voltage regulator supports a wide input voltage range of 7V to 36V9. Inputs feature bidirectional optocoupler isolation, supporting both passive and active digital inputs; active inputs support both positive and negative voltages10. Outputs feature optocoupler isolation with enhanced drive capability, providing a sink current of up to 450mA (MAX)11. USB 1.1 host and device support12. Supports low-power sleep and hibernation modes13. Can be recognized as a mass storage device via USB for drag-and-drop program downloading14. Precise on-chip clock and timers15. Built-in temperature sensor for real-time chip temperature monitoring16. 12 programmable I/O (PIO) state machines for custom peripheral support17. Size: without case about 11.24 x 7.51 x 1.74 cm; with case about 11.63 x 7.9 x 1.8 cmSpecification: Package Weight One Package Weight 0.20kgs / 0.45lb One Package Size 15cm * 10cm * 4cm / 5.91inch * 3.94inch * 1.57inch Qty per Carton 80 Carton Weight 17.00kgs / 37.48lb Carton Size 47cm * 38cm * 32cm / 18.5inch * 14.96inch * 12.6inch Loading Container 20GP: 466 cartons * 80 pcs = 37280 pcs40HQ: 1083 cartons * 80 pcs = 86640 pcs

Leer Más Menos

1. Brush: copper2. Resistor: bakelite3. Rotation angle: 200 degrees4. Rotational torque: 60-150 g/cm5. Stop strength: 500 g/cm6. Mechanical strength: resistor can withstand 1 kg of pressure without breaking7. Resistance range (Ohms): 100R-1M8. Resistance variation characteristics: B9. Operating voltage: 50V (MAX)10. Rated: 0.1W11. Residual resistance: no more than 5 percent of the nominal resistance, no more than 30 ohms12. Rotational Life: 15 percent resistance change after 100 rotations without load13. Load Life: 5 percent resistance change after 3 hours of rated power14. Adjustable resistors have a wide range of applications, including home appliances and the electronic security industry. Specific products include televisions, induction cookers, rice cookers, and more.Packing List:- 10 x 500R ohm- 10 x 1K ohms- 10 x 2K ohm- 10 x 5K ohms- 10 x 10K ohm- 10 x 20K ohm- 10 x 50K ohm- 10 x 100K ohms- 10 x 200K ohms- 10 x 1M ohmSpecification: Package Weight One Package Weight 0.06kgs / 0.14lb One Package Size 15cm * 8cm * 5cm / 5.91inch * 3.15inch * 1.97inch Qty per Carton 72 Carton Weight 5.50kgs / 12.13lb Carton Size 47cm * 34cm * 32cm / 18.5inch * 13.39inch * 12.6inch Loading Container 20GP: 521 cartons * 72 pcs = 37512 pcs40HQ: 1210 cartons * 72 pcs = 87120 pcs

Leer Más Menos

1. This product is a high-performance, highly integrated microcontroller development board independently designed by Waveshare. Within its compact form factor, it integrates peripherals including a 3.5-inch capacitive HD IPS display, highly integrated power management IC, low-power audio codec, camera interface, 6-axis IMU (3-axis accelerometer + 3-axis gyroscope), RTC, and Micro SD card slot, facilitating development and product integration. 2. Features Raspberry Pi-designed RP2350B microcontroller chip 3. Unique dual-core/dual-architecture: Dual ARM Cortex-M33 cores + dual Hazard3 RISC-V cores, both operating at up to 150MHz, enabling flexible architecture switching 4. Built-in 520KB SRAM and 16MB on-chip Flash 5. Type-C interface eliminates orientation concerns 6. Onboard 3.5-inch capacitive touch HD IPS screen with 320 × 480 resolution and 65K colors for clear image display 7. Integrated ST7796 display driver and FT6336 capacitive touch controller using SPI and I2C interfaces respectively, minimizing pin consumption 8. Camera interface compatible with mainstream modules (e.g., OV2640, OV5640) for image/video capture 9. Onboard 3.7V MX1.25 lithium battery charge/discharge interface 10. USB 1.1 host/device support 11. Low-power sleep/hibernation modes 12. Programmable via drag-and-drop when recognized as USB mass storage 13. 22 multifunctional GPIO pins: 2×SPI, 2×I2C, 2×UART, 7×12-bit ADC, 18×PWM channels 14. Precision on-chip clock/timer modules 15. Built-in temperature sensor for real-time chip monitoring 16. 12 programmable I/O (PIO) state machines for custom peripheral supportSpecification: Package Weight One Package Weight 0.10kgs / 0.23lb One Package Size 14cm * 10cm * 5cm / 5.51inch * 3.94inch * 1.97inch Qty per Carton 48 Carton Weight 5.90kgs / 13.01lb Carton Size 30cm * 42cm * 32cm / 11.81inch * 16.54inch * 12.6inch Loading Container 20GP: 661 cartons * 48 pcs = 31728 pcs40HQ: 1535 cartons * 48 pcs = 73680 pcs

Leer Más Menos

1. 6.25-inch DSI touchscreen supporting 5-point capacitive touch.2. IPS display panel with a hardware resolution of 720 × 1560.3. Default portrait orientation; display orientation can be switched via system display settings.4. Features full lamination technology and a 6H-hardness tempered glass touch panel.5. DSI display interface and I2C touch interface.6. Compatible with Raspberry Pi; supports driver-free operation on the latest Raspberry Pi OS.7. Backlight brightness can be adjusted via software or onboard buttons.Specification: Package Weight One Package Weight 0.24kgs / 0.54lb One Package Size 19cm * 10cm * 5cm / 7.48inch * 3.94inch * 1.97inch Qty per Carton 64 Carton Weight 16.00kgs / 35.27lb Carton Size 38cm * 42cm * 34cm / 14.96inch * 16.54inch * 13.39inch Loading Container 20GP: 491 cartons * 64 pcs = 31424 pcs40HQ: 1140 cartons * 64 pcs = 72960 pcs

Leer Más Menos
