Descripción
1. Supports one-dimensional code and screen barcode scanning, capable of recognizing barcode data on mobile phones and computer screens. It is compatible with scenarios for mobile payment scanning via WeChat and Alipay.
2. Comes with a storage mode that can store up to 260,000 digital and alphabetic barcode data. It can be collected offline and then uploaded in batches to a computer.
3. Has strong compatibility, compatible with most of the current cash register systems and warehouse management systems. Supports multiple interfaces such as RS-232, USB, and PS/2.
4. Has efficient scanning performance. CCD red light decoding, with a scanning speed of up to 200 times per second. Bidirectional scanning, stable decoding, and high recognition accuracy.
5. Widely applicable in multiple industries, such as supermarkets, retail, luggage and clothing, pharmacies, libraries, and warehouses.
6. Has strong adaptability to working environments. The working temperature ranges from -10℃ to 60℃. It can scan in a wide light range of 0-100,000 lx.
7. Triggered by handheld buttons for scanning. Equipped with LED indicator lights + buzzer for prompts. The operation is intuitive and the grip conforms to ergonomic principles.
Parameters
1. Indicating methods: LED indicator lights, buzzer
2. Scanning method: Handheld button-triggered scanning
3. Supporting interfaces: RS-232, USB, PS/2
4. Scanning angle: ±65°, ±60°
5. Maximum current: 130mA
6. Maximum power: 0.494W
7. Surrounding lighting: 0 - 100000 lx
8. Storage humidity: 5% - 90%
9. Storage temperature: -20°C - 60°C
10. Operating environment temperature: -10°C - 60°C
11. Printing contrast: Greater than or equal to 30%
12. Precision: Greater than or equal to 5 mil
13. Resolution: 2500
14. Scanning speed: 200 times/second
15. Reading mode: CCD red light
16. Light source type: LED (630NM)
17. Scanning mode: Bidirectional scanning
18. Wireless battery capacity: 2000mAh
Specification:
| Package Weight |
| One Package Weight |
0.27kgs / 0.60lb |
| One Package Size |
21cm * 12cm * 10cm / 8.27inch * 4.72inch * 3.94inch |
| Carton Weight |
6.00kgs / 13.23lb |
| Carton Size |
44cm * 38cm * 32cm / 17.32inch * 14.96inch * 12.6inch |
| Loading Container |
20GP: 498 cartons * 18 pcs = 8964 pcs 40HQ: 1157 cartons * 18 pcs = 20826 pcs
|
|
