Descripción
1. High-performance chip: High-performance image processing chip is adopted to ensure high frame rate while providing high-quality images, realizing high-definition smoothness.
2. Reversing rear view: When reversing, when the app is already open, the reversing video will automatically display to realize reversing rear view (this function is limited to Android devices).
3. Electronic rearview mirror: During driving, tap the mobile app to enter the rearview video interface, and you can watch the rearview video in real time.
4. Front view and side view: It can be installed in the front, rear, left and right blind areas of the vehicle to monitor these blind areas in real time.
5. A new transmission method: smart devices and cameras are connected via wifi to realize true high-definition reversing image display, avoiding cumbersome body wiring. It is widely used in transportation equipment such as automobiles, buses, commercial vehicles, trucks, and construction vehicles.
6. Free data traffic: After the camera is powered on, a wifi hotspot is automatically built, and the mobile phone does not need Internet traffic to realize high-definition video transmission. After restarting, it will automatically connect with the phone, which is easy to use.
7. Take a picture: The image can be taken, saved, and played back in the app on the smart device.
8. Driving video: The app on the smart device side can record and save images, realize functions such as video recording and video sharing, and save important video data for backup.
9. Video playback: The app on the smart device side can play back the video files stored in memory of smart the device to reproduce the shot scene.
10. No light night vision: The scene behind the car can be seen clearly even in a dark environment, making driving and reversing at night safer.
11. Large wide-angle lens: A large wide-angle lens is used to cover the panoramic view behind the car.
12. Waterproof: IP67 waterproof standard.
13. Parameters:
Power (max): 2W
Transmission: 2.4G Wifi signal
Video: H.264
Frame rate: 20-30fps
Support device: iOS/Android
Sensor: CMOS
Image pixels: 720p
Viewing angle 175 degrees
Minimum illumination: F0.1
Power supply: DC12V???DC24V
Working current: 50-80mH
Night vision distance: 8-10 meters
Waterproof rating: IP67
Fixing method: fixed position of license plate light
Transmission distance: 10-20M
Working temperature: -20???+85 degrees Celsius
Storage temperature: -0???+125 degrees Celsius
Specification:
| Package Weight |
| One Package Weight |
0.13kgs / 0.28lb |
| One Package Size |
15cm * 9cm * 9cm / 5.91inch * 3.54inch * 3.54inch |
| Carton Weight |
8.40kgs / 18.52lb |
| Carton Size |
48cm * 42cm * 42cm / 18.9inch * 16.54inch * 16.54inch |
| Loading Container |
20GP: 314 cartons * 60 pcs = 18840 pcs
40HQ: 731 cartons * 60 pcs = 43860 pcs
|
|
