Description
1. Image sensor: CMOS IMX sensor
2. Video output: 1080P full HD (HDMI output)
3. Sensor size: 1/2.9 inch
4. Video output interface: HDMI (high-definition interface)
5. Resolution output: support 16:9, 4:3 format
6. Pixel size: 2.85 × 2.85μm
7. Frame rate: 30FPS
8. Color: R/G/B supports manual adjustment
9. Cross line: 8 horizontal lines and 8 vertical lines; line color/line size support adjustment
10. Image zoom: 8.0X times zoom in and zoom out digital zoom
11. Menu language: OSD language
12. Spectral response (wavelength): 400nm-1000nm (strong)
13. Lens type: standard C/CS interface
14. Resolution: 1920x1080 30FPS; 720P 60FPS;
15. Dynamic range: 60dB
16. PC measurement: not supported
17. White balance: support manual/automatic
18. Signal to noise ratio: 45dB
19. Mirror: support left and right/up and down
20. Black and white: support
21. Negative film: support
22. Language settings: Chinese, English, Japanese, French, German, Russian, Italian, Korean, Turkish
23. Working voltage: 12V/1A
24. Shell size: 42×42×60 mm
25. Working environment: -40~65 degrees Celsius
Specification:
| Package Weight |
| One Package Weight |
0.27kgs / 0.60lb |
| One Package Size |
16cm * 10cm * 8cm / 6.3inch * 3.94inch * 3.15inch |
| Carton Weight |
30.00kgs / 66.14lb |
| Carton Size |
50cm * 50cm * 60cm / 19.69inch * 19.69inch * 23.62inch |
| Loading Container |
20GP: 177 cartons * 98 pcs = 17346 pcs
40HQ: 412 cartons * 98 pcs = 40376 pcs
|
|
