Search results for "relay module"

1. Applicable to various platforms such as 51/AVR/AVR/ARM2. Using high current relay, AC250V/10A, DC30V/10A3. Independent wiring of the contact part, safe and reliable4. Standard interface, which can be expanded on various development boards5. With fixing screw holes for easy installation6. Size: 138x56x19.3mmSpecification: Package Weight One Package Weight 0.20kgs / 0.45lb One Package Size 15cm * 8cm * 2cm / 5.91inch * 3.15inch * 0.79inch Qty per Carton 100 Carton Weight 21.00kgs / 46.30lb Carton Size 46cm * 32cm * 32cm / 18.11inch * 12.6inch * 12.6inch Loading Container 20GP: 566 cartons * 100 pcs = 56600 pcs40HQ: 1314 cartons * 100 pcs = 131400 pcs

Read more less

Features1. Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal 2. Onboard photocoupler isolation, prevent interference from external high-voltage circuit connected to the relay 3. High quality relay, contact rating: 10A 250V AC or Less than or equal 10A 30V DC 4. ABS protection enclosure with rail-mount support, easy to install, safe to use 5. Breakout USB port and BOOT pin, make it easy to debug without disassembling the enclosure 6. PWR indicator, RGB LED, and passive buzzer outside the enclosure 7. Come with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)Specification1. Operation voltage: 5V 2. Relay channel: 8CH 3. Communication protocol: USB 4. Contact form: 1NO 1NC 5. Communication interface: Micro USBPackage List1. ABS protection enclosure (top and bottom) x 1 2. Pico-Relay-B x 1 3. Screwdriver x 1 4. Screws pack x 1Specification: Package Weight One Package Weight 0.32kgs / 0.70lb One Package Size 16cm * 12cm * 5cm / 6.3inch * 4.72inch * 1.97inch Qty per Carton 40 Carton Weight 11.50kgs / 25.35lb Carton Size 50cm * 32cm * 27cm / 19.69inch * 12.6inch * 10.63inch Loading Container 20GP: 617 cartons * 40 pcs = 24680 pcs40HQ: 1432 cartons * 40 pcs = 57280 pcs

Read more less

1. Size: 6.8CM x 2.1CM2. Main chip: NE5553. Working voltage: DC 12V/5VFeatures:1. The relay time delay and power supply is connected.Specific as follows: for 12V/5V power supply to the relay, relay not immediately and absorption, relay the output status to: normally open and public disconnect, normally closed and public conduction;Wait for delay 1-10 s (adjustable), relay and absorption, at this point, the relay outputs status to: normally open and public conduction, normally closed and public disconnected;As long as the module power continuously, this state will remain.2. The delay time is adjustable, (0-10 seconds)4. Increase the potentiometer to increase the delay time5. Increasing the capacitor C1 can increase the delay time6. With input power indicator light7. With relay pull-in indicator light8. It can control AC 220V/10A equipment. (Large control equipment 2000W)9. With relay freewheeling protection.10. Delay time formula: T=1.1RC. For example: capacitor 100uf resistor 100K T=1.1 x 100000 x 0.0001=11 secondsApplications1. The on-board equipment on the time delay, prevent excessive current when the car lighter burned on-board equipment.2. Need to have order to start the occasion, to prevent multiple devices at the same time starting current is too large burning appliances.Specification: Package Weight One Package Weight 0.02kgs / 0.05lb One Package Size 14cm * 7cm * 4cm / 5.51inch * 2.76inch * 1.57inch Qty per Carton 500 Carton Weight 12.00kgs / 26.46lb Carton Size 30cm * 50cm * 40cm / 11.81inch * 19.69inch * 15.75inch Loading Container 20GP: 444 cartons * 500 pcs = 222000 pcs40HQ: 1031 cartons * 500 pcs = 515500 pcs

Read more less

1. Start mode: button switch2. Panel material: ABS3. Electrical life: 1,000,000 times4. The default jog function: the mobile phone presses the open relay to quickly pull in and out (the default interval is 1S), and it also has a timing sharing function5. Press the jog self-locking selection button and the status light is on. At this time, it is self-locking. The mobile phone presses the open relay to pull in, and press the close relay to disconnect6. WIFI control module, no programming is required, just download an APP, connect to WIFI to control the built-in cloud. As long as the module is connected to WIFI, the mobile phone can be controlled anywhere in the country7. Main chip: WIFI module8. Working voltage: DC 5V-12V9. Dimensions: 70.5 x 27.4 x 23mmSpecification: Package Weight One Package Weight 0.08kgs / 0.18lb One Package Size 10cm * 4cm * 6cm / 3.94inch * 1.57inch * 2.36inch Qty per Carton 288 Carton Weight 21.89kgs / 48.25lb Carton Size 50cm * 50cm * 38cm / 19.69inch * 19.69inch * 14.96inch Loading Container 20GP: 280 cartons * 288 pcs = 80640 pcs40HQ: 651 cartons * 288 pcs = 187488 pcs

Read more less

1. One-button emergency stop function (STOP button) is more convenient to use2. Voltage input anti-reverse connection circuit, worry-free wiring3. Setting parameters power off, power off memory function4. Added sleep mode, automatically turn off the display if there is no operation within 5 minutes5. Working voltage: DC5-30V6. Output capacity: Controllable equipment within DC 30V/10A or AC 250V/10A7. Working temperature: -40 to 85 degrees Celsius8. Signal source: high level trigger DC 3.0V-24V9. Mounting hole: diameter 3mm10. Power consumption: 400W11. Dimensions: 70 x 40 x 23mm12. Net weight: about 44gSpecification: Package Weight One Package Weight 0.08kgs / 0.19lb One Package Size 10cm * 6cm * 4cm / 3.94inch * 2.36inch * 1.57inch Qty per Carton 356 Carton Weight 30.00kgs / 66.14lb Carton Size 50cm * 50cm * 60cm / 19.69inch * 19.69inch * 23.62inch Loading Container 20GP: 177 cartons * 356 pcs = 63012 pcs40HQ: 412 cartons * 356 pcs = 146672 pcs

Read more less

1. Features the RP2350B microcontroller chip designed by Raspberry Pi.2. Unique dual-core, dual-architecture design, equipped with a dual-core ARM Cortex-M33 processor and a dual-core Hazard3 RISC-V processor, both running at up to 150MHz, allowing users to flexibly switch between the two architectures.3. Built-in 520KB of SRAM and 16MB of on-chip Flash.4. Uses a Type-C interface, eliminating concerns about correct plug orientation.5. Uses high-quality relays, allowing connection of loads: 10A 250V AC or 10A 30V DC.6. Digital input with bidirectional optocoupler isolation, supporting passive and active digital inputs; relays support control in conjunction with switch inputs.7. On-board isolated RS485 interface for easy connection to various RS485 Modbus industrial expansion modules or sensors.8. On-board pin header interface for connecting other devices.9. On-board terminal block power interface, supporting a wide voltage range of 7~36V, convenient for industrial power supply.10. On-board RTC clock chip, supporting scheduled tasks.11. On-board W5500 Ethernet chip, extending 10/100Mbps network connectivity via SPI interface.12. PoE Ethernet port version supports external PoE modules for Power over Ethernet functionality (compliant with IEEE 802.3af standard).13. On-board optocoupler isolation to prevent high-voltage circuits connected to the relays from interfering with the control chip.14. On-board digital isolation to prevent external signals from interfering with the control chip.15. On-board integrated power isolation, providing stable isolated voltage; no additional power supply is required for the isolated end.16. On-board Micro SD card slot for external SD card storage of images or files.17. On-board buzzer, RGB LED, and power and RS485 transceiver indicator lights for easy monitoring of device operating status.18. DIN rail mountable ABS protective casing for easy installation and safer use.19. USB 1.1 host and device support.20. Supports low-power sleep and hibernation modes21. Can be recognized as a mass storage device via USB for drag-and-drop program download22. 15 multi-functional GPIO pins23. 2 SPI, 2 I2C, 2 UART, 8 12-bit ADCs, and 12 controllable PWM channels14. Precise on-chip clock and timers, temperature sensor, on-chip accelerated floating-point library15. 12 programmable I/O (PIO) state machines for custom peripheral support16. Built-in power isolation, optocoupler isolation and other protection circuits for safety, stability and reliability17. Dimensions: 175x90x40mmProduct parameters:- USB interface1. Interface type: USB Type-C2. Power supply voltage: 5V3. Functions: device power supply, USB communication and firmware download, etc.- Isolated communication Interface1. Interface type: RS4852. Interface form: terminal block3. Direction control: hardware automatic detection and control of data transmission direction4. Interface protection: provides TVS tube protection, surge and electrostatic protection5. Matching resistor: default NC, 120R matching resistor reserved, can be enabled by jumper cap- Digital Input1. Number of inputs: 8 channels2. Input voltage range: 5V ~ 36V3. Input type: passive input / active input (NPN type or PNP type)4. Isolation type: Bidirectional optocoupler isolation- Relay1. Number of channels: 8 channels2. Contact type: one normally open, one normally closed3. Isolation type: optocoupler isolation- Indicator lights1. RGB: colorful cool LED beads, customizable display color2. PWR: power indicator light, lights up red when USB is connected and voltage is detected3. TXD: transmit indicator light, lights up green when data is sent from the RS485 interface4. RXD: receive indicator light, lights up when data is received from RS485 The blue light illuminates when the interface receives data.5. Power supply range: 7V ~ 36VSpecification: Package Weight One Package Weight 0.34kgs / 0.76lb One Package Size 20cm * 12cm * 6cm / 7.87inch * 4.72inch * 2.36inch Qty per Carton 30 Carton Weight 11.30kgs / 24.91lb Carton Size 42cm * 38cm * 32cm / 16.54inch * 14.96inch * 12.6inch Loading Container 20GP: 522 cartons * 30 pcs = 15660 pcs40HQ: 1212 cartons * 30 pcs = 36360 pcs

Read more less

OverviewThe RPi Relay Board (B) is an expansion board with 8-ch relays for Raspberry Pi. It gives your Pi the ability to control high voltage products such as home appliances.Features1. Supports Raspberry Pi A+/B+/2B/3B/3B+2. High quality relays, loads up to 5A 250V AC or 5A 30V DC3. Photo coupling isolation, prevent interference from high voltage circuit4. Standard rail mount bottom case5. Onboard LEDs for indicating relays status6. Relay control pin selection jumper, allows to control the relays by custom pins other than the default pins7. Reserved control Interface, allows to work with controllers like PLC8. Comes with development resources, including examples in wiringPi, bcm2835, python, python-bottle (webpage control), and crontab (cron job)Specifications1. Power supply voltage: 5V2. Trigger signal: 3.3V/5V3. Relay channels: 8-ch4. Contact form: SPDT-NO,NC5. Closed current: 6mA (per channel)6. Connector: screw terminal block7. Dimension: 232 × 72 (mm)8. Mounting hole size: 3.0mmSpecification: Package Weight One Package Weight 0.33kgs / 0.73lb One Package Size 25cm * 9cm * 2cm / 9.84inch * 3.54inch * 0.79inch Qty per Carton 160 Carton Weight 15.00kgs / 33.07lb Carton Size 50cm * 36cm * 40cm / 19.69inch * 14.17inch * 15.75inch Loading Container 20GP: 370 cartons * 160 pcs = 59200 pcs40HQ: 859 cartons * 160 pcs = 137440 pcs

Read more less

1. Onboard voltage regulation chip, supporting a wide voltage range from 7V to 36V, and supporting PoE Ethernet power supply2. Supports control via MQTT protocol, providing Alibaba Cloud MQTT application routines3. Onboard integrated power isolation, capable of providing stable isolated voltage, and the isolated end does not require additional power supply4. Input features bidirectional optocoupler isolation, supporting passive and active switch input, built-in anti-jitter algorithm, relays support switch input linkage mode or inversion mode control5. Output uses Darlington, with optocoupler isolation, stronger driving capability, with a driving current of up to 500mA, and built-in reverse current diode protection6. Output has flash-on and flash-off functions, can be set with parameters in the instruction, automatically turns off after a certain period of time after the output is turned on7. Rail-mounted enclosure design, convenient installation, safer to use8. External indicator light, convenient for checking input/output status, MCU status and signal transmission/reception status9. Size: about 14.5 x 9 x 4 cmPackaging list:- Modbus POE ETH IO 8CH host unit x 1- Screwdriver x 1Specification: Package Weight One Package Weight 0.22kgs / 0.49lb One Package Size 18cm * 12cm * 6cm / 7.09inch * 4.72inch * 2.36inch Qty per Carton 40 Carton Weight 10.00kgs / 22.05lb Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch Loading Container 20GP: 438 cartons * 40 pcs = 17520 pcs40HQ: 1018 cartons * 40 pcs = 40720 pcs

Read more less

OverviewThe RPi Relay Board gives your Pi the ability to control high voltage/high current devices, easily makes normal home appliances become intelligent.RPi Relay Board Features1. Supports Raspberry Pi A+/B+/2B/3B/3B+2. High quality relays, loads up to 5A 250V AC or 5A 30V DC3. Photo coupling isolation, prevent interference from high voltage circuit4. Onboard LEDs for indicating relays status5. Relay control jumper, allows to control the relays by custom pins other than the default pins6. Comes with development resources, including examples in wiringPi, WebioPi, shell, python, and bcm2835What is on the RPi Relay Board1. Raspberry Pi GPIO interface: for connecting Raspberry Pi2. Relay screw terminal: for connecting target devices3. Relays4. Photocoupler: PC8175. Relay indicator- LED on: relay NC is opened, NO is closed- LED off: relay NC is closed, NO is opened6. Power indicator7. Relay control jumper- Short the jumper: control the relays by default I/Os used in the example code- Open the jumper: control the relays by custom I/Os through jumper wiresPackage include- RPi Relay Board x 1- RPi screws pack (2pcs) x 1Specification: Package Weight One Package Weight 0.08kgs / 0.18lb One Package Size 8cm * 7cm * 2cm / 3.15inch * 2.76inch * 0.79inch Qty per Carton 700 Carton Weight 52.50kgs / 115.74lb Carton Size 56cm * 35cm * 40cm / 22.05inch * 13.78inch * 15.75inch Loading Container 20GP: 340 cartons * 700 pcs = 238000 pcs40HQ: 789 cartons * 700 pcs = 552300 pcs

Read more less

1. 15A current overload protection switch, real-time monitoring of electricity safety 2. Low-voltage start-up is more practical, with a trigger module to achieve 10V start-up, and no trigger device 60V start-up voltage is as low as possible 3. Input voltage: AC 220V 4. Output voltage: 0-220V adjustable (Voltmeter does not work when the output voltage is lower than 5V) 5. Limit power: 4000W (suitable for 1000W-2000W motor load) 6. Voltage adjustment range: 0-220V steplessly adjustable (under load conditions), step down to 0V, step up from 10V 7. Rated current: 9A 8. Limit current: 18ASpecification: Package Weight One Package Weight 0.58kgs / 1.28lb One Package Size 13cm * 13cm * 8cm / 5.12inch * 5.12inch * 3.15inch Qty per Carton 30 Carton Weight 17.40kgs / 38.36lb Carton Size 41cm * 28cm * 42cm / 16.14inch * 11.02inch * 16.54inch Loading Container 20GP: 553 cartons * 30 pcs = 16590 pcs40HQ: 1283 cartons * 30 pcs = 38490 pcs

Read more less

1. The relay uses high-quality alloy terminals, and the internal contacts are silver-plated. 2. Durable, firm and stable contact load, high power ideal for universal 12V applications.3. Function: 12VDC (14V Max) 4-Pin SPST (single pole single throw) Relay with 120A high switching capability. Perfect for split charging or various automotive applications.4. High 120A coil capacity, able to handle those high current applications with ease. Heavy duty make or break (on/off) relay.5. Equipped with terminal and gaskets to make installation simple and easy.Specification: Package Weight One Package Weight 0.28kgs / 0.61lb One Package Size 11.5cm * 7.5cm * 6.5cm / 4.53inch * 2.95inch * 2.56inch Qty per Carton 80 Carton Weight 20.60kgs / 45.41lb Carton Size 44cm * 36cm * 32cm / 17.32inch * 14.17inch * 12.6inch Loading Container 20GP: 526 cartons * 80 pcs = 42080 pcs40HQ: 1221 cartons * 80 pcs = 97680 pcs

Read more less

Thermostat parameters: 1. Voltage: 220V 2. Opening size: 45x45mm 3. Control method: PID control 4. Input method: K/EPT100 (optional) 5. Output mode: SSR solid state relay 6. Product size: 48x48x110mm Solid state module parameters: 1. Control method: DC control AC 2. Input voltage: 3-32V DC 3. Ambient temperature: -30 degrees Celsius to +70 degrees Celsius 4. Working frequency: 50-60Hz 5. Control current: 3-35mADC 6. Product size: 45x27x58mm 7. Product weight: 81g Screw type thermocouple parameters: 1. Model: K type 2. Screw specification: M6 inch 3. Lead length: 1 meter 4. Measuring range: 0-400 degrees Celsius 5. Wiring terminal: U-shaped terminal 6. Product weight: 16g Specification: Package Weight One Package Weight 0.35kgs / 0.77lb One Package Size 13cm * 9cm * 6cm / 5.12inch * 3.54inch * 2.36inch Qty per Carton 50 Carton Weight 21.00kgs / 46.30lb Carton Size 47cm * 32cm * 28cm / 18.5inch * 12.6inch * 11.02inch Loading Container 20GP: 633 cartons * 50 pcs = 31650 pcs40HQ: 1470 cartons * 50 pcs = 73500 pcs

Read more less
